AMD @ Computex 2021 : Everything They Announced!

AMD @ Computex 2021 : Everything They Announced!

AMD unveiled a WHOLE SLEW of new products and technologies at Computex 2021!

Here is a recap of everything AMD announced at Computex 2021!



AMD @ Computex 2021 : Everything They Announced!

On 1 June 2021, AMD kicked off their virtual Computex 2021 press conference, announcing a whole slew of new products and technologies!

Let’s take a look at what AMD announced at Computex 2021!

3rd Gen EPYC Beats Intel Xeon Scalable!

AMD President and CEO Dr. Lisa Su showed how the dual-socket 3rd Gen EPYC 7763 system beat the dual-socket Intel Xeon Platinum 8380 system by 50%!

  • 2P Intel Xeon Platinum 8380 delivered 201,334 Java operations per second
  • 2P AMD EPYC 7763 delivered 301,297 Java operations per second

This is because the EPYC 7763 has far more cores than the Xeon Platinum 8380 – 64 cores versus just 40 cores!

AMD RDNA 2 Coming To Automotive + Mobile!

AMD is working to bring the RDNA 2 gaming architecture to industry leaders in the automotive and mobile segments :

Tesla Model S + Model X

The new infotainment systems in the Tesla Model S and Model X are powered by an AMD Ryzen Embedded APU, with an AMD RDNA 2-based GPU capable of AAA gaming!

Samsung Exynos

The next-generation Samsung Exynos SoC will feature custom AMD RDNA 2-based graphics IP, that will introduce raytracing and variable rate shading capabilities to flagship mobile devices!

AMD Ryzen 5000G Desktop APUs

Dr. Lisa Su also announced that they are introducing two AMD Ryzen 5000G series desktop APUs, that will be available to the DIY market starting 5 August 2021.

AMD Ryzen 7 5700G

The AMD Ryzen 7 5700G has an 8-core, 16-thread processor, with a base clock of 3.8 GHz and a boost clock of 4.6 GHz.

It has 4 GB of L2 cache, and 16 GB of L3 cache; and 8-core integrated Radeon graphics clocked at 2.0 GHz.

This 65 watt desktop APU will have a launch price of US$359.

AMD Ryzen 5 5600G

The AMD Ryzen 5 5600G has an 6-core, 12-thread processor, with a base clock of 3.9 GHz and a boost clock of 4.4 GHz.

It has 3 GB of L2 cache, and 16 GB of L3 cache; and 7-core integrated Radeon graphics clocked at 1.9 GHz.

This 65 watt desktop APU will have a launch price of US$259.

AMD Ryzen PRO 5000 Series Desktop CPUs

While not mentioned in the main Computex 2021 press conference, AMD also launched the Ryzen PRO 5000 series desktop processors based on the Zen 3 core!

AMD Ryzen PRO 5000 G-Series (65W)

  • Ryzen 7 5750G : 8 core, 16 thread, 3.8 GHz to 4.6 GHz, 4 MB L2, 16 MB L3
  • Ryzen 5 5650G : 6 core, 12 thread, 3.9 GHz to 4.4 GHz, 3 MB L2, 16 MB L3
  • Ryzen 3 5350G : 4 core, 8 thread, 4.0 GHz to 4.2 GHz, 2 MB L2, 8 MB L3

AMD Ryzen PRO 5000 GE-Series (35W)

  • Ryzen 7 5750GE : 8 core, 16 thread, 3.2 GHz to 4.6 GHz, 4 MB L2, 16 MB L3
  • Ryzen 5 5650GE : 6 core, 12 thread, 3.4 GHz to 4.4 GHz, 3 MB L2, 16 MB L3
  • Ryzen 3 5350GE : 4 core, 8 thread, 3.6 GHz to 4.2 GHz, 2 MB L2, 8 MB L3

You can get the full details in this official AMD deep dive into the Ryzen PRO 5000 series desktop processors!

AMD Radeon RX 6000M Series Mobile Graphics

Scott Herkelman, Vice President & General Manager of AMD Graphics Business Unit, officially announced the introduction of the Radeon RX 6000M series mobile graphics for laptop gaming.

AMD Radeon RX 6800M

Their flagship model has a 2.3 GHz game clock and 12 GB of GDDR6 memory, and is designed to deliver 120 fps gaming at 1440p.

AMD says that it will offer significantly better performance than the competition :

  • 40% to 70% better gaming performance than the GeForce RTX 2070 at 1440p Max Settings.
  • 14% to 40% better gaming performance than the GeForce RTX 3080 while gaming on battery.

AMD Radeon RX 6700M

This model has a 2.3 GHz game clock and 10 GB of GDDR6 memory, and is designed to deliver 100 fps gaming at 1440p.

AMD Radeon RX 6600M

This model has a 2.177 GHz game clock and 8 GB of GDDR6 memory, and is designed to deliver 100 fps gaming at 1080p.

AMD FidelityFX Super Resolution (FSR)

FidelityFX Super Resolution, or FSR for short, is AMD’s spatial upscaling technology that is designed to boost frame rates, while delivering a high-quality gaming experience.

Think of it as AMD’s version of NVIDIA’s DLSS. But while DLSS is proprietary, FidelityFX Super Resolution is open-source, and will be supported on both AMD processors and GPUs as well as NVIDIA GPUs!

More than 10 game developers plan to integrate FSR into their top titles and gamer engines in 2021.

AMD FidelityFX Super Resolution (FSR) will be available starting 22 June 2021.

AMD Advantage Gaming Laptops

Think of AMD Advantage as a marketing programme, based around a “design framework” of premium gaming features.

  • Amplified Performance : AMD Ryzen processor + AMD Radeon RX 6800M graphics + AMD Radeon Software for gaming at 100 fps at 1080p
  • Premium Displays : 144Hz+ with LFC, low latency, AMD FreeSync Premium, 300 nits+ brightness, IPS / OLED panels, 100% sRGB / 72% NTSC minimum
  • Built To Game : NVMe SSD, less than 40°C WASD keyboard temperatures when gaming, >10 hours binge watching on battery

AMD 3D Chiplet Technology

AMD continues to build on their packaging technologies with their new 3D Chiplet technology, developed in collaboration with TSMC.

It enhances their existing chipset architecture with 3D stacking using a hybrid bond approach that provides over 200X the interconnect density of 2D chipsets and more than 15X the density of existing 3D packaging solutions.

This new 3D chiplet technology also consumes less energy than current 3D solutions, and is the most flexible active-on-active silicon stacking technology.

In Computex 2021, Dr. Lisa Su showed off the 3D vertical SRAM cache bonded to an AMD Ryzen 5000 Series processor prototype.

AMD is on-track to begin production on high-end computing products with 3D chiplets by the end of 2021.



Help Support My Work!

If you would like to support my work, you can do so via bank transfer /  PayPal / credit card.

Name : Adrian Wong

Credit Card / Paypal : https://paypal.me/techarp
Bank Transfer : CIMB 7064555917 (Swift Code : CIBBMYKL)

Thank you in advanced!



Recommended Reading

Go Back To > Computer | GamingTech ARP



Support Tech ARP!

If you like our work, you can help support us by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


Ryzen 7 3700C | Ryzen 5 3500C | Ryzen 3 3250C Revealed!

AMD just introduced the Ryzen 7 3700C, Ryzen 5 3500C and Ryzen 3 3250C mobile processors with Radeon Graphics!

Here is what you need to know about the new AMD Ryzen 3000 C-Series mobile APUs!



Ryzen 7 3700C | Ryzen 5 3500C | Ryzen 3 3250C : Chromebooks Get A Boost!

The three new AMD Ryzen 3000 C-Series mobile processors come with integrated Radeon Graphics cores. That makes them APUs, instead of pure processors.

Built on the older Zen+ or Zen architecture and fabricated on the 12 nm or 14 nm process technology, they are designed as premium APUs for Chromebooks.

At launch, AMD is introducing three Ryzen 3000 C-Series processors, with a 15 W TDP :

  • AMD Ryzen 7 3700C : 4C/8T | up to 4.0 GHz | 6 MB cache | 10 graphics cores
  • AMD Ryzen 5 3500C : 4C/8T | up to 3.7 GHz | 6 MB cache | 8 graphics cores
  • AMD Ryzen 3 3250C : 2C/4T | up to 3.5 GHz | 5 MB cache | 3 graphics cores

These Ryzen 3000 C-Series processors will be used in premium Chromebook laptops, offering significantly better performance than the old AMD A-Series APUs, and better performance than the AMD Ryzen 3000 C-Series processors.

Although they are not part of these processors, Chromebooks based on the AMD Ryzen 3000 C-Series will feature Wi-Fi 6 and Bluetooth 5 connectivity.

The AMD A-Series APUs, with a 6 W TDP, will continue to ship in entry-level Chromebooks.



Ryzen 7 3700C | Ryzen 5 3500C | Ryzen 3 3250C : Specifications

Specifications Ryzen 7
3700C
Ryzen 5
3500C
Ryzen 3
3250C
Architecture Zen+ Zen
Process 12 nm 14 nm
Cores / Threads 4 / 8 2 / 4
Base Clock 2.3 GHz 2.1 GHz 2.6 GHz
Boost Clock 4.0 GHz 3.7 GHz 3.5 GHz
L1 Cache 256 KB 128 KB
L2 Cache 2 MB 1 MB
L3 Cache 4 MB
Graphics Cores 10 8 3
Graphics Clock 1.4 GHz 1.2 GHz
TDP 15 W



Ryzen 7 3700C | Ryzen 5 3500C | Ryzen 3 3250C : Performance

According to AMD, the new Ryzen 3000 C-Series mobile APUs offer double to triple the web browsing performance, compared to the A6-9220C.

Their graphics performance is even better, with the Ryzen 7 3700C offering 2.5X more performance than the A6-9220C in 3DMark Sling Shot and PCMark’s Photo Editing test.



Ryzen 7 3700C | Ryzen 5 3500C | Ryzen 3 3250C : Availability

AMD will only say that their partners – HP, ASUS and Lenovo – will introduce six Chromebook laptops in 2020, powered by the new Ryzen and Athlon 3000 C-Series APUs.

No specifics about the models and choice of processor yet. We will keep you updated when we learn more.



Recommended Reading

Go Back To > ComputerHome



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD Athlon Gold 3150C + Athlon Silver 3050C Revealed!

AMD just introduced the Athlon Gold 3150C and Athlon Silver 3050C mobile processors with Radeon Graphics!

Here is what you need to know about the new AMD Athlon 3000 C-Series mobile APUs!



Athlon Gold 3150C + Athlon Silver 3050C : Zen Comes To Chromebooks!

The two new AMD Athlon 3000 C-Series mobile processors come with integrated Radeon Graphics cores. That makes them APUs, instead of pure processors.

Built on the older Zen architecture and fabricated on the 14 nm process technology, they are designed to power Chromebooks.

At launch, AMD is introducing these two Athlon 3000 C-Series processors, both with a 15 W TDP :

  • AMD Athlon Gold 3150C : 2C/4T | up to 3.3 GHz | 5 MB cache | 3 graphics cores
  • AMD Athlon Silver 3050C : 2C/2T | up to 3.2 GHz | 5 MB cache | 2 graphics cores

These Athlon 3000 C-Series processors will be used in mid-level Chromebooks, offering better performance than the old AMD A-Series APUs, but less than the AMD Ryzen 3000 C-Series processors.

The AMD A-Series APUs, with a 6 W TDP, will continue to ship in entry-level Chromebooks.

Although they are not part of these processors, Chromebooks based on the AMD Athlon 3000 C-Series will feature Wi-Fi 6 and Bluetooth 5 connectivity.



Athlon Gold 3150C + Athlon Silver 3050C : Specifications

Specifications Athlon Gold
3150C
Athlon Silver
3050C
Architecture Zen
Process 14 nm
Cores / Threads 2 / 4 2 / 2
Base Clock 2.4 GHz 2.3 GHz
Boost Clock 3.3 GHz 3.2 GHz
L1 Cache 128 KB
L2 Cache 1 MB
L3 Cache 4 MB
Graphics Cores 3 2
Graphics Clock 1.1 GHz
TDP 15 W



Athlon Gold 3150C + Athlon Silver 3050C : Availability

AMD will only say that their partners – HP, ASUS and Lenovo – will introduce six Chromebook laptops in 2020, powered by the new Ryzen and Athlon 3000 C-Series APUs.

No specifics about the models and choice of processor yet. We will keep you updated when we learn more.



Recommended Reading

Go Back To > ComputerHome



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD Ryzen PRO 4000 Desktop APUs : All You Need To Know!

AMD just unveiled the Ryzen PRO 4000 Series of desktop APUs, with integrated Radeon Graphics!

Here is what you need to know about the new AMD Ryzen PRO 4000 desktop APUs!



AMD Ryzen PRO 4000 Desktop APUs with Radeon Graphics

Like the recently released Ryzen PRO 4000 Mobile APUs, the Ryzen 4000 Series come with integrated Radeon Graphics cores. That makes them APUs, instead of pure processors.

While these new desktop APUs are called the 4000 series, they are still part of the 3rd Gen Ryzen processor family, and based on the AMD Zen 2 architecture.

At launch, AMD is introducing six Ryzen PRO 4000 Series desktop processors, three with a 65W TDP :

  • AMD Ryzen 7 PRO 4750G : 8C/16T | up to 4.4 GHz | 12 MB cache | 8 graphics cores
  • AMD Ryzen 5 PRO 4650G : 6C/12T | up to 4.2 GHz | 11 MB cache | 7 graphics cores
  • AMD Ryzen 3 PRO 4350G : 4C/8T | up to 4.0 GHz | 6 MB cache | 6 graphics cores

And three desktop APUs with a 35W TDP :

  • AMD Ryzen 7 PRO 4750GE : 8C/16T | up to 4.3 GHz | 12 MB cache | 8 graphics cores
  • AMD Ryzen 5 PRO 4650GE : 6C/12T | up to 4.2 GHz | 11 MB cache | 7 graphics cores
  • AMD Ryzen 3 PRO 4350GE : 4C/8T | up to 4.0 GHz | 6 MB cache | 6 graphics cores



AMD Ryzen PRO 4000 Desktop APUs : Specifications Compared!

We also summarised the key specifications of the six models in this table for easier comparison :

Specifications Ryzen 7
PRO
4750G
Ryzen 7
PRO
4750GE
Ryzen 5
PRO
4650G
Ryzen 5
PRO
4650GE
Ryzen 3
PRO
4350G
Ryzen 3
PRO
4350GE
Cores / Threads 8 / 16 6 / 12 4 / 8
Base Clock 3.6 GHz 3.1 GHz 3.7 GHz 3.3 GHz 3.8 GHz 3.5 GHz
Boost Clock 4.4 GHz 4.3 GHz 4.2 GHz 4.0 GHz
L1 Cache 512 KB 384 KB 256 KB
L2 Cache 4 MB 3 MB 2 MB
L3 Cache 8 MB 4 MB
Graphics Cores 8 7 6
Graphics Clock 2.1 GHz 2.0 GHz 1.9 GHz 1.7 GHz
TDP 65 W 35 W 65 W 35 W 65 W 35 W



AMD Ryzen PRO 4000 Desktop APUs : Performance

AMD shared with us this chart to show how much of a performance advantage the new Ryzen PRO 4000 desktop APUs have over the last generation Ryzen PRO 3400G :

AMD Ryzen 7 PRO 4750G vs Intel Core i7-9700 vPro

In this comparison, the Ryzen 7 PRO 4750G offers significant performance advantage over the Intel Core i7-9700 vPro.

Of course, this isn’t really a fair fight, since they are comparing a 8C/16T processor against an 8C/8T processor.

AMD Ryzen 7 PRO 4650G vs Intel Core i7-9500 vPro

And the Ryzen 7 PRO 4650G is naturally much faster than the Intel Core i7-9500 vPro.

Again, this is a lopsided comparison of an 6C/12T processor against an 6C/6T processor.



AMD Ryzen PRO 4000 Series : Price + Availability

Unfortunately, all six desktop APUs will be limited to the OEM market initially.

AMD does not plan to introduce them to the retail market, until later. So there is no information on their price or retail availability.

AMD expects desktops with these processors to ship from system integrators starting today, 21 July 2020, and from AMD OEM partners like Lenovo and HP starting in Q4 2020.



Recommended Reading

Go Back To > Computer | BusinessHome



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD Athlon 3000 G-Series with Radeon Graphics Revealed!

Together with the Ryzen 4000 G-Series, AMD also unveiled the Athlon 3000 G-Series with Radeon Graphics!

Here is what you need to know about the new AMD Athlon 3000 G-Series desktop APUs!



AMD Athlon 3000 G-Series with Radeon Graphics Desktop APUs

Unlike the recently released Ryzen 3000 XT series, the Athlon 3000 G-Series come with integrated Radeon Graphics cores. That makes them APUs, instead of pure processors.

These Athlon models are part of the 3rd Gen Ryzen processor family, and based on the AMD Zen 2 architecture.

At launch, AMD is introducing three Athlon 4000 G-Series processors :

  • AMD Athlon Gold 3150G : 4C/4T | 3.9 GHz | 6 MB cache | 3 graphics cores | 65W TDP
  • AMD Athlon Gold 3150GE : 4C/4T | 3.8 GHz | 6 MB cache | 3 graphics cores35W TDP
  • AMD Athlon Silver 3050GE : 2C/4T | 3.4 GHz | 5 MB cache | 3 graphics cores35W TDP



AMD Athlon 3000 G-Series : Specifications Compared!

We also summarised the key specifications of the three models in this table for easier comparison :

Specifications Athlon Gold
3150G
Athlon Gold
3150GE
Athlon Silver
3050GE
Cores / Threads 4 / 4 2 / 4
Base Clock 3.9 GHz 3.8 GHz 3.4 GHz
Boost Clock NA NA NA
L1 Cache 256 KB 128 KB
L2 Cache 2 MB 1 MB
L3 Cache 4 MB
Graphics Cores 3
Graphics Clock 1.1 GHz
TDP 65 W 35 W



AMD Athlon 3000 G-Series : Price + Availability

Unfortunately, all three Athlon desktop APUs will be limited to the OEM market initially.

AMD does not plan to introduce them to the retail market, until later. So there is no information on their price or retail availability.

AMD expects desktops with these processors to ship from OEM partners like Lenovo and HP starting in Q3 2020.



Recommended Reading

Go Back To > Computer | BusinessHome



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD Ryzen 4000 G-Series with Radeon Graphics Revealed!

On the heels of the Ryzen 3000 XT series, AMD just unveiled the Ryzen 4000 G-Series with Radeon Graphics!

Here is what you need to know about the new AMD Ryzen 4000 G-Series desktop APUs!



AMD Ryzen 4000 G-Series with Radeon Graphics Desktop APUs

Unlike the recently released Ryzen 3000 XT series, the Ryzen 4000 G-Series come with integrated Radeon Graphics cores. That makes them APUs, instead of pure processors.

While these new desktop APUs are called the 4000 series, they are still part of the 3rd Gen Ryzen processor family, and based on the AMD Zen 2 architecture.

At launch, AMD is introducing six Ryzen 4000 G-Series processors, three with a 65W TDP :

  • AMD Ryzen 7 4700G : 8C/16T | up to 4.4 GHz | 12 MB cache | 8 graphics cores
  • AMD Ryzen 5 4600G : 6C/12T | up to 4.2 GHz | 11 MB cache | 7 graphics cores
  • AMD Ryzen 3 4300G : 4C/8T | up to 4.0 GHz | 6 MB cache | 6 graphics cores

And three desktop APUs with a 35W TDP :

  • AMD Ryzen 7 4700GE : 8C/16T | up to 4.3 GHz | 12 MB cache | 8 graphics cores
  • AMD Ryzen 5 4600GE : 6C/12T | up to 4.2 GHz | 11 MB cache | 7 graphics cores
  • AMD Ryzen 3 4300GE : 4C/8T | up to 4.0 GHz | 6 MB cache | 6 graphics cores



AMD Ryzen 4000 G-Series : Specifications Compared!

We also summarised the key specifications of the six models in this table for easier comparison :

Specifications Ryzen 7
4700G
Ryzen 7
4700GE
Ryzen 5
4600G
Ryzen 5
4600GE
Ryzen 3
4300G
Ryzen 3
4300GE
Cores / Threads 8 / 16 6 / 12 4 / 8
Base Clock 3.6 GHz 3.1 GHz 3.7 GHz 3.3 GHz 3.8 GHz 3.5 GHz
Boost Clock 4.4 GHz 4.3 GHz 4.2 GHz 4.0 GHz
L1 Cache 512 KB 384 KB 256 KB
L2 Cache 4 MB 3 MB 2 MB
L3 Cache 8 MB 4 MB
Graphics Cores 8 7 6
Graphics Clock 2.1 GHz 2.0 GHz 1.9 GHz 1.7 GHz
TDP 65 W 35 W 65 W 35 W 65 W 35 W



AMD Ryzen 4000 G-Series : Performance

AMD shared with us this chart to show how much of a performance advantage their Ryzen 4000 G-Series desktop APUs have over the 9th Gen Intel Core processors :



AMD Ryzen 4000 G-Series : Price + Availability

Unfortunately, all six desktop APUs will be limited to the OEM market initially.

AMD does not plan to introduce them to the retail market, until later. So there is no information on their price or retail availability.

AMD expects desktops with these processors to ship from OEM partners like Lenovo and HP starting in Q3 2020.



Recommended Reading

Go Back To > Computer | BusinessHome



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD 25×20 Initiative : Goals FAR Exceeded!

AMD just announced that they FAR exceeded the goals of the 25×20 initiative they set in 2014.

Join us for a quick video overview of the AMD 25×20 Initiative, and how far they exceeded those goals!



AMD 25×20 Initiative : What Is It?

Back in 2014, AMD mobile APUs were widely panned for their poor energy efficiency. That ensured the continued dominance of Intel mobile processors in the laptop market.

So they challenged themselves to dramatically improve the real-world energy efficiency of their mobile processors, setting the moonshot goal of delivering at least 25 times better energy efficiency by the year 2020.

That is essentially the crux of the AMD 25×20 initiative.



AMD 25×20 Initiative : Goals FAR Exceeded!

Six years later, AMD announced that they far exceeded the goals of their 25×20 initiative.

With the introduction of their 3rd Gen AMD Ryzen 4000 series of mobile APUs (codenamed Renoir), they actually delivered 31.7X more energy efficiency!

AMD achieved their 25×20 goals by delivering :

  • New CPU and GPU architectures tightly integrated into a common SoC
  • New innovations in real-time power management
  • Continued evolution of the AMD Infinity Fabric architecture
  • Silicon-level power optimizations
  • Rapid adoption of the latest process technologies (28nm > 14nm > 12nm > 7nm)



AMD 25×20 Initiative : The Impact

To illustrate the impact of this leap in energy efficiency, AMD shared these calculations.

If an enterprise upgrades 50,000 AMD laptops from 2014 models to 2020 models, it would save approximately 1.4 million kilowatt hours of electricity and 971,000 kg of carbon emissions,

That would be roughly equivalent to growing 16,000 trees for 10 years!



Recommended Reading

Go Back To > Computer Hardware | Business | Home

Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD Ryzen 4000 Mobile : Major Consumer Kick-Off In 2020!

AMD just kicked off a major consumer roll-out of the AMD Ryzen 4000 family of mobile processors!

Join us for AMD’s official consumer tech briefing, and compare the full stack of Ryzen 4000 consumer and PRO mobile processors!



AMD Ryzen 4000 Mobile : Major Consumer Kick-Off In 2020!

The AMD Ryzen 4000 family of mobile processors was first unveiled at CES 2020, but its major roll-out got delayed due to the COVID-19 pandemic.

To take on Intel’s considerable control of the laptop market, AMD prepared a formidable stack of 14 mobile processors – all with integrated Vega graphics.

To kick-off their 2020 assault on Intel’s mobile market stronghold, AMD lined up these laptops with their partners :

  • ASUS G14 : Ryzen 4000 H-series + NVIDIA + AMD FreeSync
  • ASUS G15 : Ryzen 4000 H-series + NVIDIA + AMD FreeSync
  • MSI Bravo : Ryzen 4000 H-series + Radeon RX 5500M + AMD FreeSync
  • Lenovo Legion 5 : Ryzen 4000 H-series + NVIDIA
  • Dell G5 15 SE : Ryzen 4000 H-series + Radeon RX 5600M + AMD FreeSync + AMD SmartShift

Recommended : AMD Radeon RX 5700M | RX 5600M : A Quick Primer!



AMD SmartShift : A Special Mention!

AMD SmartShift is a new technology that gives the new AMD Ryzen 4000 mobile processors better performance – up to 10% in games, and 12% in content creation.

It is basically a smart power distribution technique that dynamically improves CPU or GPU performance with a limited power budget.

For more details, we recommend reading AMD SmartShift Explained : Smart Power Distribution FTW!

Unfortunately, it’s not launching in all Ryzen 4000 laptops, only the Dell G5 15 SE at this time. So if you want to take advantage of this new AMD technology, we highly recommend you check out the Dell G5 15 SE.



AMD Ryzen 4000 Mobile : Specifications

For your convenience, here is a table comparing the key specifications of the full stack of AMD Ryzen 4000 mobile processors – both consumer-grade and PRO-grade models.

Processor Model Cores /
Threads
cTDP Base
Clock
Boost
Clock
L2
Cache
L3
Cache
GPU
Cores
GPU
Clock
Ryzen 9 4900H 8 / 16 45 W 3.3 GHz 4.4 GHz 4 MB 8 MB 8 1.75 GHz
Ryzen 9 4900HS 8 / 16 35 W 3.0 GHz 4.3 GHz 4 MB 8 MB 8 1.75 GHz
Ryzen 7 4800H 8 / 16 45 W 2.9 GHz 4.2 GHz 4 MB 8 MB 7 1.6 GHz
Ryzen 7 4800HS 8 / 16 35 W 2.9 GHz 4.2 GHz 4 MB 8 MB 7 1.6 GHz
Ryzen 7 4800U 8 / 16 15 W 1.8 GHz 4.2 GHz 4 MB 8 MB 8 1.75 GHz
Ryzen 7 PRO 4750U 8 / 16 15 W 1.7 GHz 4.1 GHz 4 MB 8 MB 7 1.6 GHz
Ryzen 5 4700U 8 / 8 15 W 2.0 GHz 4.1 GHz 4 MB 8 MB 7 1.6 GHz
Ryzen 5 PRO 4650U 6 / 12 15 W 2.1 GHz 4.0 GHz 3 MB 8 MB 6 1.5 GHz
Ryzen 5 4600H 6 / 12 45 W 3.0 GHz 4.0 GHz 3 MB 8 MB 6 1.5 GHz
Ryzen 5 4600HS 6 / 12 35 W 3.0 GHz 4.0 GHz 3 MB 8 MB 6 1.5 GHz
Ryzen 5 4600U 6 / 12 15 W 2.1 GHz 4.0 GHz 3 MB 8 MB 6 1.5 GHz
Ryzen 5 4500U 6 / 6 15 W 2.3 GHz 4.0 GHz 3 MB 8 MB 6 1.5 GHz
Ryzen 3 PRO 4450U 4 / 8 15 W 2.5 GHz 3.7 GHz 2 MB 4 MB 5 1.4 GHz
Ryzen 3 4300U 4 / 4 15 W 2.7 GHz 3.7 GHz 2 MB 4 MB 5 1.4 GHz



AMD Ryzen 4000 Mobile : More Videos!

Just in case you missed them, here are more videos on the AMD Ryzen 4000 mobile processor family!

AMD Ryzen Mobile 4000 Series Official CES 2020 Briefing

AMD Ryzen Mobile 4000 Series Performance

AMD Ryzen Mobile 4000 Series Gaming Performance

AMD Ryzen Mobile 4000 Series Battery Life



Recommended Reading

Go Back To > Computer Hardware | Home

Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD Ryzen PRO 4000 Mobile APUs : A Quick Primer!

Together with their Spring 2020 desktop Ryzen launch, AMD also launched the Ryzen PRO 4000 mobile APUs for professional laptops!

Here is EVERYTHING AMD has revealed so far about the new Ryzen PRO 4000 mobile APUs!



3rd Gen Ryzen 4000 Mobile Family : An Overview

The 3rd Gen Ryzen 4000 Mobile processor family comes in three product line-ups :

  • PRO-series for professional laptops
  • 45 watt H-series for high-performance laptops, and
  • 15 watt U-series for low-power ultra-thin laptops.

All three series boasts the same architectural features :

  • Built on the 7nm process technology
  • 512 KB L2 cache per core
  • 4 MB L3 cache for 2 / 4-core parts
  • 8 MB L3 cache for 6 / 8-core parts
  • LPDDR4x memory support
  • Integrated Radeon Vega Graphics (5 to 8 cores)
  • support AMD SmartShift

Recommended : AMD SmartShift Explained : Smart Power Distribution FTW!



AMD Ryzen PRO 4000 Mobile APUs : A Quick Primer!

AMD announced three models under the new Ryzen PRO 4000 Mobile family :

AMD Ryzen 7 PRO 4750U

  • Designed for ultra-thin business laptops, with 8 cores and 16 threads
  • Up to 33% better multi-threaded performance than the competition
  • Up to 2.2X better graphics performance than the competition
  • Up to 2X better performance per watt over previous generation

AMD Ryzen 5 PRO 4650U

  • Designed for ultra-thin business laptops, with 6 cores and 12 threads
  • Up to 2X better multi-threaded performance than the competition
  • Up to 2.3X better graphics performance than the competition
  • Up to 2X better performance per watt over previous generation

AMD Ryzen 3 PRO 4550U

  • Designed for ultra-thin business laptops, with 4 cores and 8 threads



AMD Ryzen PRO 4000 Mobile APUs : Specifications

Specifications Ryzen 7
PRO
4750U
Ryzen 5 PRO
4650U
Ryzen 3 PRO
4450U
Process 7 nm + 12 nm
Cores / Threads 8 / 16 6 / 12 4 / 8
Base Clock 1.7 GHz 2.1 GHz 2.5 GHz
Boost Clock 4.1 GHz 4.0 GHz 3.7 GHz
L2 Cache 4 MB 3 MB 2 MB
L3 Cache 8 MB 4 MB
GPU Cores 7 6 5
Memory
Support
DDR4-3200
LPDDR4-4266
TDP 15 W



Recommended Reading

Go Back To > Computer Hardware | Home

Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD Ryzen 9 4900H : 8C/16T High Performance Mobile APU!

AMD just introduced the Ryzen 9 4900H – a high-performance 8-core, 16-thread mobile processor with a TDP of 45 watts!

Here is EVERYTHING on the AMD Ryzen 9 4900H, including four new Ryzen Mobile 4000 Series videos!



AMD Ryzen 4000 H-Series

The AMD Ryzen 9 4900H is part of the new Ryzen 4000 H-Series, which consists at launch of just these two models :

  • Ryzen 9 4900H : 8 cores, 16 threads, 3.3 GHz base clock, 4.4 GHz boost clock
  • Ryzen 7 4800H : 8 cores, 16 threads, 2.9 GHz base clock, 4.2 GHz boost clock
  • Ryzen 5 4600H : 6 cores, 12 threads, 3.0 GHz base clock, 4.0 GHz boost clock

Recommended : 3rd Gen Ryzen 4000 Mobile Family : A Quick Primer!



AMD Ryzen 9 4900H Mobile APU

The AMD Ryzen 9 4900U not only comes with 8 cores, it also supports simultaneous multithreading, allowing it to process up to 16 threads at the same time.

It has a 4 MB L2 cache and an 8 MB L3 cache, with a 3.3 GHz base clock and a 4.4 GHz boost clock. It comes with a Radeon Vega 8 Graphics integrated GPU that runs at 1.75 GHz.

The AMD Ryzen 9 4900H has a nominal TDP of 45 watts, but is configurable by the laptop manufacturer for a TDP of 35 watts to 45 watts.

Like the other AMD Ryzen 4000 Mobile processors, it is fabricated on the 7 nm process, and supports LPDDR4x memory. It also has SmartShift capability, when paired with a separate Radeon GPU.

AMD Ryzen Mobile 4000 Series Performance

AMD Ryzen Mobile 4000 Series Gaming Performance

AMD Ryzen Mobile 4000 Series Battery Life



AMD Ryzen 9 4900H Specifications Compared

Here is a comparison of the AMD Ryzen 9 4900H against the other members of the AMD Ryzen 4000 Mobile family.

Processor Model Cores /
Threads
cTDP Base
Clock
Boost
Clock
L2
Cache
L3
Cache
GPU GPU
Clock
Ryzen 9 4900H 8 / 16 45 W 3.3 GHz 4.4 GHz 4 MB 8 MB Vega 8 1.75 GHz
Ryzen 7 4800H 8 / 16 45 W 2.9 GHz 4.2 GHz 4 MB 8 MB Vega 7 1.6 GHz
Ryzen 7 4800U 8 / 16 15 W 1.8 GHz 4.2 GHz 4 MB 8 MB Vega 8 1.75 GHz
Ryzen 5 4700U 8 / 8 15 W 2.0 GHz 4.1 GHz 4 MB 8 MB Vega 7 1.6 GHz
Ryzen 5 4600H 6 / 12 45 W 3.0 GHz 4.0 GHz 3 MB 8 MB Vega 6 1.5 GHz
Ryzen 5 4600U 6 / 12 15 W 2.1 GHz 4.0 GHz 3 MB 8 MB Vega 6 1.5 GHz
Ryzen 5 4500U 6 / 6 15 W 2.3 GHz 4.0 GHz 3 MB 8 MB Vega 6 1.5 GHz
Ryzen 3 4300U 4 / 4 15 W 2.7 GHz 3.7 GHz 2 MB 4 MB Vega 5 1.4 GHz



AMD Ryzen 9 4900H Gaming Performance

The AMD Ryzen 9 4900U is targeted directly at the Intel Core i7-9750H, offering 39% better gaming performance, according to AMD.





Recommended Reading

Go Back To > Computer Hardware | Home

Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD Athlon 3000G : The Last Raven Ridge APU Unlocked!

Together with the Ryzen 9 3950X, AMD just launched their last Raven Ridge APU – the Athlon 3000G!

Here is EVERYTHING you need to know about the AMD Athlon 3000G, and how it compares against the older Raven Ridge APUs!

Updated @ 2019-11-26 : Added Singapore purchase link.

Updated @ 2019-11-22 : Added the official AMD Athlon 3000G price for Malaysia.

Updated @ 2019-11-20 : Added UK purchase links, and some minor corrections.

Originally posted @ 2019-11-07



Introducing The AMD Athlon 3000G

The AMD Raven Ridge soldiers on for one more hurrah! Introducing the AMD Athlon 3000G in this video is Don Woligroski, AMD Desktop Processor Technical Marketing Manager.



AMD Athlon 3000G : The Last Raven Ridge APU!

The 3000G is what AMD calls an Accelerated Processing Unit, because it combines a processor with a graphics processor in a single die.

It comes with two Zen processor cores that are capable of handling four simultaneous threads, and a Radeon Vega 3 GPU with 12 texture units and 4 ROPs.

Priced at just US$49, the Athlon 3000G has a fixed 3.5 GHz clock speed, with a 35 W TDP. It comes with a 1 MB L2 cache and a 4 MB L3 cache. Unlike earlier Raven Ridge APUs though, the 3000G has been unlocked for overclocking.

However, this will be the (last and) only Raven Ridge Athlon to be released this year, so don’t expect a higher clocked part. Don Woligroski confirmed this in the Q&A session (see this video)

Recommended : AMD Ryzen 9 3950X : Everything You Need To Know!



AMD Athlon 3000G Specifications

As this table shows, the Athlon 3000G is basically the Athlon 240GE with a 100 MHz faster Vega 3 GPU, that has been unlocked for easier overclocking.

Specifications Athlon
3000G
Athlon
240GE
Athlon
220GE
Athlon
200GE
Fab Process 14 nm
Cores / Threads 2 / 4
Base Clock 3.5 GHz 3.5 GHz 3.4 GHz 3.2 GHz
Boost Clock NA NA NA NA
L2 Cache 1 MB
L3 Cache 4 MB
Vega Graphics Vega 3 (1100 MHz) Vega 3 (1000 MHz)
Memory Support DDR4-2667 (Dual Channel)
TDP 35 W
Launch Price $49 $75 $65 $55



How Fast Is The AMD Athlon 3000G?

AMD is targeting the 3000G against the Intel Pentium G5400, which retails at $73 – almost 50% higher.

According to AMD’s benchmarks, it will offer better performance across the board, at ⅔ of the cost.

Because it’s very similar to last year’s Athlon 240GE, AMD unlocked the 3000G to allow for easier overclocking.

If you overclock it by 400 MHz to 3.9 GHz, you will see even better performance over the Intel Pentium G5400 :



AMD Athlon 3000G Price + Availability

The AMD Athlon 3000G has a recommended retail price of just US$49 / RM209, and it will be available for purchase from 19 November 2019 onwards.

Here are some online purchase options (we will update it when more opportunities come online) :

This makes it 35% cheaper than the Athlon 240GE ($75) when it was first launched. But of course, that was a year ago!



Recommended Reading

Go Back To > Computer Hardware | Home

Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


Official AMD Athlon PRO with Radeon Vega Graphics Tech Briefing

AMD just announced the Athlon PRO family of processors, together with the consumer-grade “regular” AMD Athlon APU with Radeon Vega Graphics. This new processor is basically the AMD Athlon APU with enterprise-grade security and reliability features.

In this article, we will share with you the official AMD tech briefing on the AMD Athlon PRO with Radeon Vega Graphics APUs, including the official slides, and other details.

Don’t forget to check out the Official AMD Athlon APU with Radeon Vega Graphics Tech Briefing and the Official 2nd Gen Ryzen PRO Desktop CPU Tech Briefing!



The Official AMD Athlon PRO with Radeon Vega Graphics Tech Briefing

Let’s start with the official Athlon PRO tech briefing by David Tjong, AMD Product Marketing Manager. This is an improved video that we created with larger, sharper slides and gaps removed. Enjoy!



AMD Athlon PRO with Radeon Vega Graphics

The AMD Athlon PRO with Radeon Vega Graphics is what AMD calls an Accelerated Processing Unit, because it combines a processor with a graphics processor in a single die.

In the Athlon PRO’s case, it is basically a cut-down version of the AMD Ryzen PRO APUs launched in May 2018 – a combination of a Ryzen CPU with a Radeon Vega graphics processor, with enterprise-grade security and reliability features.

Most of the built-in security features are already part of the consumer-grade AMD Athlon APU. The PRO version adds on quality assurances and warranty, as well as manageability features for businesses and enterprises.

[adrotate group=”1″]



AMD Athlon PRO 200GE

AMD officially launched only one PRO APU on 6 September 2018 – the AMD Athlon PRO 200GE with Radeon Vega 3 Graphics. It has exactly the same performance characteristics as the consumer-grade AMD Athlon 200GE APU.

The Athlon PRO 200GE has two Zen processor cores that is capable of handling four simultaneous threads, with three Radeon Vega Graphics compute units. It has a fixed 3.2 GHz clock speed, with a 35 W TDP. It comes with a 1 MB L2 cache and a 4 MB L3 cache.



Where Does The AMD Athlon PRO Fit In?

The AMD Athlon PRO with Radeon Vega Graphics is meant to be a basic processor option with basic graphics capabilities.

It slots in below the AMD Ryzen 3 PRO models, and competes directly against the Intel Pentium G4560, which AMD notes, uses more power and lacks Intel vPro security and manageability features.

With just two Zen cores and three Vega CUs, it’s definitely not meant for serious graphics or video work. But it will be more than powerful enough to power an office PC. In fact, AMD sees it powering a new slew of thin and compact desktop PCs.

New Page > AMD Athlon PRO Performance, Price + Availability, Official Slides



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


How Fast Is The AMD Athlon PRO?

AMD pit their Athlon PRO 200GE against the Intel Pentium G4560. A couple of differences to note :

  • The Athlon PRO 200GE runs at 3.2 GHz, while the Pentium G4560 runs at 3.5 GHz.
  • The Athlon PRO 200GE has 5 MB of L2 and L3 cache, while the Pentium G4560 only has a 2 MB L2 cache.
  • The Athlon PRO 200GE runs a 35 W TDP, while the Pentium G4560 has a 54 W TDP.
  • The Athlon PRO 200GE supports DDR4-2933 memory, while the Pentium G4560 only supports DDR4-2400 memory.

According to AMD, the Athlon PRO 200GE is slightly slower than the Pentium G4560 in CPU performance, but has 67% better graphics performance with a 35% lower TDP.

In light workloads, AMD claims that the 200GE performs just as well as the Pentium G4560.

For large enterprises whose IT teams have to deploy hundreds or thousands of PCs, this may matter more. According to a third-party study commissioned by AMD, deploying an AMD system is no different than deploying an Intel system – they both take the same number of steps.

In fact, the study also showed that it takes an IT team slightly less time to deploy an AMD system than an equivalent Intel system. This may not matter much with a few systems, but when you are dealing with a hundreds or thousands of systems, it could mean hours and days saved.



AMD Athlon PRO Price + Availability

The AMD Athlon PRO 200GE APU is available with immediate effect to AMD OEM partners, but their eventual system availability will depend on the respective OEM launch schedules. Right now, you can look forward to these system :

  • HP EliteDesk G4 – in full tower, mini tower and SFF form factors
  • Lenovo ThinkCentre M715q Tiny
  • Dell OptiPlex 5055



Complete Set of AMD Athlon PRO Presentation Slides



Suggested Reading

[adrotate group=”2″]

Go Back To > First PageComputer Hardware + Systems | Home



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


AMD Athlon APU with Radeon Vega Graphics Tech Report!

AMD just introduced the AMD Athlon APU with Radeon Vega Graphics. They are essentially a new low-cost family of processors based on the AMD Raven Ridge APUs launched earlier this year.

In this article, we will share with you the official AMD Athlon APU with Radeon Vega Graphics tech briefing, as well as the official slides, and other details.



The Official AMD Athlon APU with Radeon Vega Graphics Tech Briefing

Let’s start with the official AMD Athlon APU with Radeon Vega Graphics tech briefing by Robert Hallock, AMD Senior Technical Marketing Manager. This is an improved video that we created with larger, sharper slides and gaps removed. Enjoy!



AMD Athlon APU with Radeon Vega Graphics

The AMD Athlon APU with Radeon Vega Graphics is what AMD calls an Accelerated Processing Unit, because it combines a processor with a graphics processor in a single die.

In the Athlon APU’s case, it is basically a cut-down version of the AMD Raven Ridge APUs launched in February 2018. It combines a Ryzen CPU with a Radeon Vega graphics processor.



What Are The New AMD Athlon APU Models?

AMD officially launched only one Athlon APU on 6 September 2018 – the AMD Athlon 200GE with Radeon Vega 3 Graphics. It has two Zen processor cores that is capable of handling four simultaneous threads, with three Radeon Vega Graphics compute units.

Priced at just US$55, the Athlon 200GE has a fixed 3.2 GHz clock speed, with a 35 W TDP. It comes with a 1 MB L2 cache and a 4 MB L3 cache.

AMD also announced that the AMD Athlon 220GE and Athlon 240GE models (specifications unknown) will be released sometime in Q4 2018.



What Motherboards Does It Support?

The AMD Athlon APU with Radeon Vega Graphics runs on the AMD AM4 platform. So you can upgrade your existing AM4 system with the new Athlon APU (with a BIOS upgrade).

Although AMD did not explicitly mention it, the AMD Athlon APU with Radeon Vega Graphics most likely supports the faster DDR4-2933 memory, so it may pay to upgrade to a newer motherboard that supports the higher DDR4 memory speed.

[adrotate group=”1″]



Where Does The AMD Athlon APU Fit In?

The AMD Athlon APU with Radeon Vega Graphics is meant to be a basic processor option with basic graphics capabilities. It slots in below the AMD Ryzen 3 CPU and APU models, and competes directly against the Intel Pentium and Celeron models.

With just two Zen cores and three Vega CUs, it’s definitely not meant for serious gaming. But it will be more than powerful enough to power a family computer, or a cheap office PC.

New Page > AMD Athlon APU Performance, Price + Availability, Official Slides



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


How Fast Is The AMD Athlon APU?

AMD pit their Athlon 200GE against the Intel Pentium G4560. A couple of differences to note :

  • The Athlon 200GE runs at 3.2 GHz, while the Pentium G4560 runs at 3.5 GHz.
  • The Athlon 200GE has 5 MB of L2 and L3 cache, while the Pentium G4560 only has a 2 MB L2 cache.
  • The Athlon 200GE runs a 35 W TDP, while the Pentium G4560 has a 54 W TDP.
  • The Athlon 200GE supports DDR4-2933 memory, while the Pentium G4560 only supports DDR4-2400 memory.

The AMD Athlon 200GE was roughly equal to the Pentium G4560 in CPU performance, but has 67% better graphics performance with a 35% lower TDP. AMD estimates that this mades the Athlon 200GE 2X more efficient than the Pentium G4560.



A Generational Boost From Zen

Here are more benchmark comparison (sadly with no actual numbers) comparing the Athlon 200GE against the Pentium G4560, and the previous-generation AMD A6-9500E APU. The Athlon 200GE is notably twice as fast as the A6-9500E.



Can You Game On The AMD Athlon APU?

Well, you can… if you are satisfied with your games running at 720p. Still, it is far better than what’s possible with the processor graphics of the Intel Pentium G4560 or the A6-9500E APU.

You can boost its gaming performance with a discrete graphics card, although it will be hobbled a little by its PCIe x8 support (instead of PCIe x16).

In this test, AMD used the NVIDIA GeForce GTX 1050. The Intel Pentium G4560 was a little faster, but requires more power.



AMD Athlon APU Price + Availability

The AMD Athlon 200GE is priced at US$ 55, and will be available from global retailers and system integrators starting 18 September 2018, while the Athlon 220GE and 240GE processor models are slated for launch in Q4 2018.

[adrotate group=”1″]



The Complete AMD Athlon APU Presentation Slides

Here is a complete set of the official AMD Athlon APU with Radeon Vega Graphics presentation slides for your perusal.



Recommended Reading

[adrotate group=”2″]

Go Back To > First PageComputer Hardware + Systems | Home



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!


The AMD Ryzen PRO Mobile APU Tech Report

AMD just announced the availability of seven Ryzen PRO APU models for the mobile and desktop markets, as well as laptops and desktops featuring these new APUs. Get the full details of the new AMD Ryzen PRO Mobile APUs – features, specifications and availability!



AMD Raven Ridge

Raven Ridge is AMD’s codename for their Ryzen-Vega APUs (Accelerated Processing Units). First introduced in the mobile segment as the AMD Ryzen Mobile, AMD is now offering PRO versions in both mobile and desktop markets.

These Ryzen APUs combine an AMD Ryzen CPU, with an AMD Radeon Vega GPU, in a single die.

Ryzen CPU + Radeon Vega GPU = Ryzen APU

Mobile APUs are not new. AMD have been making them for years, and Intel mobile processors all come with integrated graphics. But AMD is still the only manufacturer to integrate “premium CPU cores” with “premium graphics cores”.



AMD Ryzen PRO APU

The AMD Ryzen PRO desktop processors, revealed in September 2017, were enterprise-grade versions of the first-generation AMD Ryzen 7 and Ryzen 5 processors. A month later, AMD launched the AMD Ryzen Mobile APUs.

However, AMD has not launched any enterprise-grade APU for either the desktop or mobile market… until now, that is. Here are the first seven AMD Ryzen PRO APU models – three for the mobile market, and four for the desktop market.

AMD Ryzen PRO APU (Mobile SKUs)

  • AMD Ryzen 7 PRO 2700U – 4C/8T, 2.2 to 3.8 GHz, Vega 11 Graphics, 15W cTDP
  • AMD Ryzen 5 PRO 2500U – 4C/8T, 2.0 to 3.6 GHz, Vega 8 Graphics, 15W cTDP
  • AMD Ryzen 3 PRO 2300U – 4C/4T, 2.0 to 3.4 GHz, Vega 6 Graphics, 15W cTDP

AMD Ryzen PRO APU (Desktop SKUs)

  • AMD Ryzen 5 PRO 2400G – 4C/8T, 3.6 to 3.9 GHz, Vega 11 Graphics, 65W TDP
  • AMD Ryzen 5 PRO 2400GE – 4C/8T, 3.2 to 3.8 GHz, Vega 11 Graphics, 35W TDP
  • AMD Ryzen 3 PRO 2200G – 4C/4T, 3.5 to 3.7 GHz, Vega 8 Graphics, 65W TDP
  • AMD Ryzen 3 PRO 2200GE – 4C/4T, 3.2 to 3.6 GHz, Vega 8 Graphics, 35W TDP

In this article, we will focus on the Ryzen PRO Mobile APUs. For the AMD Ryzen PRO desktop APUs, we have a separate article – The AMD Ryzen PRO Desktop APU Tech Report.



Ryzen PRO Mobile APU Specifications

SpecificationsAMD Ryzen 7 PRO 2700UAMD Ryzen 5 PRO 2500UAMD Ryzen 3 PRO 2300U
CCX Configuration4+04+04+0
CPU Cores444
CPU Threads884
Base Clock2.2 GHz2.0 GHz2.0 GHz
Boost Clock3.8 GHz3.6 GHz3.4 GHz
L1 Cache64 KB instruction cache
32 KB data cache
64 KB instruction cache
32 KB data cache
64 KB instruction cache
32 KB data cache
L2 Cache512 KB x 4512 KB x 4512 KB x 4
L3 Cache4 MB4 MB4 MB
Integrated GPURadeon RX Vega 10
- 640 stream processors
- 40 TMUs, 16 ROPs
- Up to 1300 MHz
Radeon RX Vega 8
- 512 stream processors
- 32 TMUs, 16 ROPs
- Up to 1100 MHz
Radeon RX Vega 6
- 384 stream processors
- 24 TMUs, 8 ROPs
- Up to 1100 MHz
Memory SupportUp to DDR4-2400 (Dual Channel)Up to DDR4-2400 (Dual Channel)Up to DDR4-2400 (Dual Channel)
TDP15 W Nominal
12-25 W (Configurable)
15 W Nominal
12-25 W (Configurable)
15 W Nominal
12-25 W (Configurable)

Next Page > AMD Ryzen PRO Mobile APU Key Features



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

AMD Ryzen PRO Mobile APU Key Features

AMD GuardMI Technology

Even though the Ryzen PRO APU uses the same silicon as its consumer-grade siblings, it has AMD GuardMI Technology enabled.

GuardMI is built into the silicon, which offers OS-agnostic security through :

  • Transparent Secure Memory Encryption – DRAM encryption with minimal performance impact
  • Secure Boot Process – hardware-based root of trust secures the BIOS from power-on
  • Real-Time Intrusion Detection – with support for fTPM and TPM 2.0



Enterprise-Grade Reliability

The AMD Ryzen PRO APU will come with enterprise-grade reliability features like :

  • 18 months of planned software stability
  • 24 months of planned processor availability
  • commercial-grade quality-assurance process
  • cherry-picked silicon for long-term reliability and performance
  • supports DASH manageability standard
  • 36-month limited warranty for system manufacturers



Single CCX Configuration

Unlike the Summit Ridge-based Ryzen CPUs, the AMD Raven Ridge processors use a single CCX configuration. This is a cost-saving measure with a much smaller die size, that also yield some performance benefits – reduced cache and memory latencies.



Precision Boost 2

The AMD Ryzen PRO APU also boasts the improved Precision Boost 2, whose more graceful and linear boost algorithm allows them to “boost more cores, more often, on more workloads“. It is now able to change frequencies in very fine granularity of just 25 MHz.

According to AMD, this will allow the AMD Ryzen PRO APU to perform better with apps that spawn many lightweight threads, as opposed to apps with persistent loads (e.g. video editing and 3D rendering).

[adrotate group=”1″]



Mobile XFR (mXFR)

Mobile XFR (eXtended Frequency Range) is the automatic overclocking feature that boosts the processor voltage and clock speed beyond the Precision Boost clock speed. It leverages the temperature awareness of Precision Boost 2 to determine how much faster it can overclock.

Like the desktop XFR feature, it is highly dependent on the processor temperature, so a good cooling solution is necessary. Notebooks must have coolers that meet AMD’s performance criteria if they want to offer mXFR.



Synergistic Power Rail Sharing

The AMD Ryzen PRO mobile APUs have a unified VDD power rail with digital low-dropout (LDO) regulators. This synergistic power rail sharing allows the maximum current requirements to be reduced by 36%.

They also have multiple digital LDO regions for the CPU cores, graphics core and subregions. This allows those regions to be completely turned off when they are idle, greatly saving power.

The shared voltage regulators not only reduce the total current draw, it allows the Ryzen PRO mobile APU to gain a higher peak CPU and GPU current to boost performance.

Next Page > AMD Ryzen PRO Mobile APU Performance



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

AMD Ryzen PRO Mobile APU Performance

Let’s take a look at some benchmark results that AMD shared with us.

General Office Productivity

In general office productivity apps, the AMD Ryzen 7 PRO 2700U is about 95% as fast as the Intel Core i7-8550U. The AMD Ryzen 5 PRO 2500U, on the other hand, is equivalent to the Intel Core i5-8250U.

Professional Applications

Thanks to the integrated Vega Graphics, the AMD Ryzen PRO Mobile APUs shine in professional applications. They are slightly faster in Photoshop, but offer significantly better performance in 3D CAD applications.

Desktop-Class Performance

Despite being a mobile processor, the Ryzen PRO Mobile offers desktop-class performance at a fraction of the power.

Ryzen PRO Mobile vs. 8th Gen Core

AMD shared some benchmarks to show you how the new AMD Ryzen PRO Mobile APUs fare against their Intel 8th Gen Core counterparts.

Ryzen PRO Mobile vs. 8th Gen vPro

Here are some benchmarks demonstrating how much faster the new AMD Ryzen PRO Mobile APUs again, compared to the Intel 8th Gen vPro counterparts.

[adrotate group=”1″]



AMD Ryzen PRO Mobile APU Gaming Performance

Even though the AMD Ryzen PRO Mobile APUs are “technically” used only for work <wink wink>, the integrated Vega Graphics allow them to double as esports gaming systems! In fact, AMD shares that the AMD Ryzen 7 PRO 2700U is as fast as the Intel Core i7-8550U paired with the NVIDIA GeForce 950M GPU.

Now, the integrated Vega Graphics is not meant to be a true gaming GPU, but it is powerful enough to deliver playable frame rates for these games at 1080p resolution.

Next Page > AMD Ryzen PRO Mobile APU Availability + Slides



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

AMD Ryzen PRO Mobile APU Availability

The AMD Ryzen PRO Mobile APUs (and Ryzen PRO desktop APUs) are already available to OEMs, with AMD announcing the following designs for both SME businesses, as well as enterprises.



Suggested Reading



AMD Ryzen PRO Mobile APU Slides

Here is the complete set of AMD Ryzen PRO Mobile APU slides for your perusal.

Go Back To > First PageComputer Hardware & Systems | Home



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

The AMD Ryzen PRO Desktop APU Tech Report

AMD just announced the availability of seven Ryzen PRO APU models for the mobile and desktop markets, as well as laptops and desktops featuring these new APUs. Get the full details of the new AMD Ryzen PRO desktop APU – features, specifications and availability!



AMD Raven Ridge

Raven Ridge is AMD’s codename for their Ryzen-Vega APUs (Accelerated Processing Units). First introduced in the mobile segment as the AMD Ryzen Mobile, AMD is now offering PRO versions in both mobile and desktop markets.

These Ryzen APUs combine an AMD Ryzen CPU, with an AMD Radeon Vega GPU, in a single die.

Ryzen CPU + Radeon Vega GPU = Ryzen APU

Desktops APUs are not new. AMD have been making them for years, and many Intel desktop processors come with integrated graphics. But AMD is still the only manufacturer to integrate “premium CPU cores” with “premium graphics cores”.



AMD Ryzen PRO Desktop APU

The AMD Ryzen PRO desktop processors, revealed in September 2017, were enterprise-grade versions of the first-generation AMD Ryzen 7 and Ryzen 5 processors. A month later, AMD launched the AMD Ryzen Mobile APUs.

However, AMD has not launched any enterprise-grade APU for either the desktop or mobile market… until now, that is. Here are the first seven AMD Ryzen PRO APU models – three for the mobile market, and four for the desktop market.

AMD Ryzen PRO APU (Mobile SKUs)

  • AMD Ryzen 7 PRO 2700U – 4C/8T, 2.2 to 3.8 GHz, Vega 11 Graphics, 15W cTDP
  • AMD Ryzen 5 PRO 2500U – 4C/8T, 2.0 to 3.6 GHz, Vega 8 Graphics, 15W cTDP
  • AMD Ryzen 3 PRO 2300U – 4C/4T, 2.0 to 3.4 GHz, Vega 6 Graphics, 15W cTDP

AMD Ryzen PRO APU (Desktop SKUs)

  • AMD Ryzen 5 PRO 2400G – 4C/8T, 3.6 to 3.9 GHz, Vega 11 Graphics, 65W TDP
  • AMD Ryzen 5 PRO 2400GE – 4C/8T, 3.2 to 3.8 GHz, Vega 11 Graphics, 35W TDP
  • AMD Ryzen 3 PRO 2200G – 4C/4T, 3.5 to 3.7 GHz, Vega 8 Graphics, 65W TDP
  • AMD Ryzen 3 PRO 2200GE – 4C/4T, 3.2 to 3.6 GHz, Vega 8 Graphics, 35W TDP

In this article, we will focus on the Ryzen PRO desktop APUs. For the AMD Ryzen PRO Mobile APUs, we have a separate article – The AMD Ryzen PRO Mobile APU Tech Report.

[adrotate group=”1″]



Ryzen PRO Desktop APU Specifications

SpecificationsAMD Ryzen 5 PRO 2400GAMD Ryzen 5 PRO 2400GEAMD Ryzen 3 PRO 2200GAMD Ryzen 3 PRO 2200GE
CCX Configuration4+04+04+04+0
CPU Cores4444
CPU Threads8844
Base Clock3.6 GHz3.2 GHz3.5 GHz3.2 GHz
Boost Clock3.9 GHz3.8 GHz3.7 GHz3.6 GHz
L1 Cache64 KB instruction cache
32 KB data cache
64 KB instruction cache
32 KB data cache
64 KB instruction cache
32 KB data cache
64 KB instruction cache
32 KB data cache
L2 Cache512 KB x 4512 KB x 4512 KB x 4512 KB x 4
L3 Cache4 MB4 MB4 MB4 MB
Integrated GPURadeon RX Vega 10
- 640 stream processors
- 40 TMUs, 16 ROPs
- Up to 1300 MHz
Radeon RX Vega 8
- 512 stream processors
- 32 TMUs, 16 ROPs
- Up to 1100 MHz
Radeon RX Vega 8
- 512 stream processors
- 32 TMUs, 16 ROPs
- Up to 1100 MHz
Radeon RX Vega 8
- 512 stream processors
- 32 TMUs, 16 ROPs
- Up to 1100 MHz
Memory SupportUp to DDR4-2933 (Dual Channel)Up to DDR4-2933 (Dual Channel)Up to DDR4-2933 (Dual Channel)Up to DDR4-2933 (Dual Channel)
TDP65 W35 W65 W35 W

Next Page > AMD Ryzen PRO Desktop APU Key Features



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

AMD Ryzen PRO Desktop APU Key Features

AMD GuardMI Technology

Even though the Ryzen PRO APU uses the same silicon as its consumer-grade siblings, it has AMD GuardMI Technology enabled.

GuardMI is built into the silicon, which offers OS-agnostic security through :

  • Transparent Secure Memory Encryption – DRAM encryption with minimal performance impact
  • Secure Boot Process – hardware-based root of trust secures the BIOS from power-on
  • Real-Time Intrusion Detection – with support for fTPM and TPM 2.0



Enterprise-Grade Reliability

The AMD Ryzen PRO APU will come with enterprise-grade reliability features like :

  • 18 months of planned software stability
  • 24 months of planned processor availability
  • commercial-grade quality-assurance process
  • cherry-picked silicon for long-term reliability and performance
  • supports DASH manageability standard
  • 36-month limited warranty for system manufacturers



Single CCX Configuration

Unlike the Summit Ridge-based Ryzen CPUs, the AMD Raven Ridge processors use a single CCX configuration. This is a cost-saving measure with a much smaller die size, that also yield some performance benefits – reduced cache and memory latencies.



[adrotate group=”2″]

Smaller L3 Cache

Using a single CCX configuration halves the Raven Ridge L3 cache size from 8 MB to 4 MB. To compensate, AMD increased their base and boost clock speeds.



New CPU Package

The Raven Ridge APUs also introduce a revised CPU package, and a switch to the traditional non-metallic TIM (thermal interface material). These are again cost-cutting measures, albeit with a side benefit of allowing the Raven Ridge processors to officially support DDR4-2933 memory.



Precision Boost 2

The AMD Ryzen PRO APU also boasts the improved Precision Boost 2, whose more graceful and linear boost algorithm allows them to “boost more cores, more often, on more workloads“. It is now able to change frequencies in very fine granularity of just 25 MHz.

According to AMD, this will allow the AMD Ryzen PRO APU to perform better with apps that spawn many lightweight threads, as opposed to apps with persistent loads (e.g. video editing and 3D rendering).



PCIe x8 For Discrete GPU

The Summit Ridge-based AMD Ryzen 7, Ryzen 5 and Ryzen 3 processors have 16 PCI Express 3.0 lanes dedicated to the PCIe graphics card. In Raven Ridge, that gets cut down to half. That means any external graphics card will only communicate with a Raven Ridge processor at PCIe x8 speed.

This is a cost-saving measure, making the Raven Ridge processor simpler and cheaper to produce. AMD also claims that the move contributed to a smaller and more efficient uncore.

Next Page > AMD Ryzen PRO Desktop APU Performance & Availability



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

AMD Ryzen PRO Desktop APU Performance

We haven’t had the opportunity to benchmark these desktop APUs, but they should perform similarly to the consumer-grade Raven Ridge desktop APUs we reviewed earlier :

Let’s take a look at some benchmark results that AMD shared with us.

General Office Productivity

In general office productivity apps, the AMD Ryzen PRO 5 2400G was just under 90% as fast as the Intel Core i5-8400. The AMD Ryzen PRO 3 2200G, on the other hand, was slightly faster than the Intel Core i3-8100.

Professional Applications

Thanks to the integrated Vega Graphics, the AMD Ryzen PRO desktop APUs shine in professional applications. The AMD Ryzen PRO 5 2400G performed up to 2.8X faster than the Intel Core i5-8400. The AMD Ryzen PRO 3 2200G, on the other hand, was up to 2X faster than the Intel Core i3-8100.



AMD Ryzen PRO Desktop APU Availability

The AMD Ryzen PRO desktop APUs (and Ryzen PRO Mobile APUs) are already available to OEMs, with AMD announcing the following designs for both SME businesses, as well as enterprises.



Suggested Reading

Next Page > AMD Ryzen PRO Desktop APU Slides



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

AMD Ryzen PRO Desktop APU Slides

Here is the complete set of AMD Ryzen PRO desktop APU slides for your perusal.



Suggested Reading

Go Back To > First PageComputer Hardware & Systems | Home



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

The AMD Raven Ridge Desktop APU Tech Report Rev. 3.0

At CES 2018, AMD announced the AMD Raven Ridge desktop processors – the long-awaited AMD Ryzen APUs. They are basically AMD Ryzen processors with AMD Radeon Vega graphics built-in. We can now share with you the full details and our reviews of the AMD Raven Ridge desktop APUs!

Updated @ 2018-02-13 : Added the AMD Ryzen 5 2400G and Ryzen 3 2200G review links. Updated various parts of the article.

Updated @ 2018-02-10 : Added two new sections on the new CPU package, L3 cache, PCI Express lanes, and Precision Boost 2. Also updated the section on the Single CCX Configuration.

Originally posted @ 2018-02-08

[/su_spoiler]



The AMD Raven Ridge Desktop APU Reviews

Here are the reviews of the new AMD Raven Ridge desktop APUs.



The AMD Raven Ridge Desktop APUs

Raven Ridge is AMD’s codename for their Ryzen-Vega APUs (Accelerated Processing Units). First introduced in the mobile segment as the AMD Ryzen Mobile, AMD is now introducing them to the desktop market.

The new Ryzen APUs combine an AMD Ryzen CPU, with an AMD Radeon Vega GPU, in a single die.

AMD Ryzen CPU + AMD Radeon Vega GPU = AMD Ryzen APU

Desktops APUs are not new. AMD have been making them for years, and many Intel desktop processors come with integrated graphics. But AMD is still the only manufacturer to integrate “premium CPU cores” with “premium graphics cores” to deliver gaming for the masses with :

  • 1080p HD+ gaming performance without a discrete graphics card
  • support for Radeon FreeSync, Radeon Chill, Enhanced Sync and Radeon ReLive



Single CCX Configuration

Unlike the Summit Ridge-based Ryzen CPUs, the AMD Raven Ridge processors use a single CCX configuration. This is a cost-saving measure with a much smaller die size, that also yield some performance benefits – reduced cache and memory latencies.

AMD analysed the performance of the 2+2 and 4+0 configuration and concluded that they are “roughly equivalent on average across 50+ games“.



Smaller L3 Cache

Using a single CCX configuration halves the Raven Ridge L3 cache size from 8 MB to 4 MB. To compensate, AMD increased their base and boost clock speeds, particularly in the Ryzen 5 2400G.



New CPU Package

The Raven Ridge APUs also introduce a revised CPU package, and a switch to the traditional non-metallic TIM (thermal interface material). These are again cost-cutting measures, albeit with a side benefit of allowing the Raven Ridge processors to officially support DDR4-2933 memory.

[adrotate group=”1″]



Precision Boost 2

The new Raven Ridge processors also boast the improved Precision Boost 2, whose more graceful and linear boost algorithm allows them to “boost more cores, more often, on more workloads“. It is now able to change frequencies in very fine granularity of just 25 MHz.

According to AMD, this will allow the Raven Ridge processors to perform better with apps and games that spawn many lightweight threads, as opposed to apps with persistent loads (e.g. video editing and 3D rendering).



PCIe x8 For Discrete GPU

The Summit Ridge-based AMD Ryzen 7, Ryzen 5 and Ryzen 3 processors have 16 PCI Express 3.0 lanes dedicated to the PCIe graphics card. In Raven Ridge, that gets cut down to half. That means any external graphics card will only communicate with a Raven Ridge processor at PCIe x8 speed.

This is a cost-saving measure, making the Raven Ridge processor simpler and cheaper to produce. The Ryzen 3 2200G, for example, is $10 cheaper than its predecessor, the Ryzen 3 1200. They also claim that the move contributed to a smaller and more efficient uncore.

AMD made this decision because “abundant public data has shown that this is a neutral change for the midrange GPUs and workloads likely to be paired with a $99-169 processor“.

Frankly, the Raven Ridge is best used as-is. If you plan to use a discrete graphics card, it makes far more sense to get the Summit Ridge-based AMD Ryzen 7, Ryzen 5 and Ryzen 3 processors instead.

Next Page > Unboxing Raven Ridge, Specifications, Price & Availability



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

The AMD Ryzen 2000G Series APUs Revealed!

As announced at CES 2018, AMD is introducing two Raven Ridge desktop processors as part of the new AMD Ryzen 2000G family – the AMD Ryzen 5 2400G, and the AMD Ryzen 3 2200G.

AMD kindly sent us their Raven Ridge desktop processor media kit, which we unboxed in this video :



The AMD Raven Ridge Desktop APU Specification Comparison

For your convenience, we created this table that compares their key specifications with those of their CPU-equivalents – the AMD Ryzen 5 1400 and the AMD Ryzen 3 1200.

SpecificationsAMD Ryzen 5 2400GAMD Ryzen 5 1400AMD Ryzen 3 1200AMD Ryzen 3 2200G
TDP65 W65 W65 W65 W
SocketAM4AM4AM4AM4
Process Technology14 nm FinFET14 nm FinFET14 nm FinFET14 nm FinFET
Transistor Count4.94 Billion4.8 Billion4.8 Billion4.94 Billion
Die Size209.78 mm²192 mm²192 mm²209.78 mm²
CCX Configuration4+02+22+24+0
Processor Cores4444
Number of Simultaneous Threads8844
L2 Cache Size2 MB2 MB2 MB2 MB
L3 Cache Size4 MB8 MB8 MB4 MB
Base Clock Speed3.6 GHz3.2 GHz3.1 GHz3.5 GHz
Boost Clock Speed3.9 GHz3.4 GHz3.4 GHz3.7 GHz
Max. DDR4 SpeedDDR4-2933DDR4-2667DDR4-2667DDR4-2933
GPURadeon RX Vega 11
- 704 stream processors
- 44 TMUs, 16 ROPs
- Up to 1250 MHz
NoneNoneRadeon Vega 8
- 512 stream processors
- 32 TMUs, 16 ROPs
- Up to 1100 MHz
PCI Express LanesPCIe x8PCIe x16PCIe x16PCIe x8
Bundled CPU CoolerAMD Wraith StealthAMD Wraith StealthAMD Wraith StealthAMD Wraith Stealth
Launch PriceUS$ 169US$ 169US$ 109US$ 99



AMD Raven Ridge Price & Availability

The AMD Raven Ridge desktop APUs are available for purchase starting 12 February 2018, at the following prices :

[adrotate group=”2″]
  • AMD Ryzen 5 2400G (review) : $169 | RM 759 (inclusive of 6% GST)
  • AMD Ryzen 3 2200G (review) : $99 | RM 479 (inclusive of 6% GST)

At those price points, these Raven Ridge APUs will literally shred Intel processors with integrated graphics to pieces with their value proposition. More cores and more threads, with a much faster graphics core, at such prices. What more can you ask for?

The AMD Raven Ridge desktop APUs will be a relief to many esports gamers, who are suffering from extremely high GPU prices because of cryptocurrency miners.



Suggested Reading

Go Back To > First PageComputer Hardware & Systems | Home



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

AMD Ryzen Mobile APUs – Everything You Need To Know!

AMD has officially announced the Ryzen Mobile APUs!. Formerly codenamed Raven Ridge, they combine the AMD Zen CPU cores with AMD Vega graphics to deliver new heights in CPU and graphics performance for ultra-thin notebooks. Let’s dive into the details of the new AMD Ryzen Mobile with Radeon Vega Graphics APUs!



AMD Ryzen Mobile “Raven Ridge” APUs

The AMD Ryzen Mobile is not just a mobile processor, it is a mobile APU (Accelerated Processing Unit). Basically, it is a combination of a traditional processor, with a GPU, using a System-on-Chip design.

The new Ryzen Mobile APU combines the new AMD Zen cores used in desktop Ryzen processors with AMD Vega cores used in the new AMD Radeon RX Vega graphics cards.

Mobile APUs are not new. Even Intel mobile processors come with integrated graphics. But AMD is still the only manufacturer to integrate “premium CPU cores” with “premium graphics cores”.

The new CPU and GPU cores used in the new Ryzen Mobile APUs allow them to deliver 3X better CPU performance, and 2.3X better GPU performance over that of equivalent 7th Gen AMD APUs. Performance isn’t everything though. The Ryzen Mobile APUs also promise to use 58% less power!

[adrotate group=”1″]



The AMD Ryzen Mobile Specifications

AMD has announced two Ryzen Mobile models – the AMD Ryzen 7 2700U and the AMD Ryzen 5 2500U. Here are their specifications.

SpecificationsAMD Ryzen 7 2700UAMD Ryzen 5 2500U
CPU Cores4 Cores4 Cores
Simultaneous Threads8 Threads8 Threads
L1 Cache64 KB instruction cache
32 KB data cache
64 KB instruction cache
32 KB data cache
L2 Cache512 KB x 4512 KB x 4
L3 Cache4 MB shared4 MB shared
Base Clock Speed2.2 GHz2.0 GHz
Boost Clock Speed3.8 GHz3.6 GHz
GPU Cores10 Radeon Vega CUs8 Radeon Vega CUs
GPU ClockUp to 1.3 GHzUp to 1.1 GHz
Memory SupportUp to DDR4-2400 (Dual Channel)Up to DDR4-2400 (Dual Channel)
TDP15 W Nominal
12-25 W (Configurable)
15 W Nominal
12-25 W (Configurable)

Next Page > Precision Boost 2, Mobile XFR, Synergistic Power Rail Sharing



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

Precision Boost 2

The AMD Ryzen Mobile APU introduces a new Precision Boost 2 algorithm that is part of the new AMD SenseMI technology. Instead of switching between a simple 2-core and all-core boost option, it is designed to dynamically seek the maximum possible clock speed according to the current CPU temperature, current and load.

It is also now able to change frequencies in very fine granularity of just 25 MHz. This allows for a smoother boost curve, and better boost clocks for different kinds of loads on-the-fly.



Mobile XFR (mXFR)

Mobile XFR (eXtended Frequency Range) is the automatic overclocking feature that boosts the processor voltage and clock speed beyond the Precision Boost clock speed. It leverages the temperature awareness of Precision Boost 2 to determine how much faster it can overclock.

Like the desktop XFR feature, it is highly dependent on the processor temperature, so a good cooling solution is necessary. Notebooks must have coolers that meet AMD’s performance criteria if they want to offer mXFR.

[adrotate group=”1″]



Synergistic Power Rail Sharing

The new AMD Ryzen Mobile APUs have a unified VDD power rail with digital low-dropout (LDO) regulators. This synergistic power rail sharing allows the maximum current requirements to be reduced by 36%.

They also have multiple digital LDO regions for the CPU cores, graphics core and subregions. This allows those regions to be completely turned off when they are idle, greatly saving power.

The shared voltage regulators not only reduce the total current draw, it allows the Ryzen Mobile APU to gain a higher peak CPU and GPU current to boost performance.

Next Page > Per-Core Control, Enhanced Gate States, Power Gating & Faster Gate Exit



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

Per-Core Frequency & Voltage

Thanks to its fine-grained integrated voltage regulation, the AMD Ryzen Mobile APUs can dynamically adjust the frequency and voltage for each core. As each processing thread has different compute requirements, this allows the Ryzen Mobile to push power to the cores that require more performance on-the-fly.

This capability is not restricted to the CPU cores. The AMD Ryzen Mobile APUs can trade power and current between the CPU and GPU as well!



Enhanced Gate States

The AMD Ryzen Mobile APUs feature enhanced gate states. The CPU cores can enter CC6 power gating individually, and the L3 cache power can be lowered when all four cores are in CC6 mode. The enhanced gate states also allow the Ryzen Mobile to power down up to 95% of the Radeon Vega graphics core.

[adrotate group=”1″]



Dual Region Power Gating

The SoC elements of the AMD Ryzen Mobile APU are organised into two types of region. The Type A Region can remain gated during display refresh, while the Type B Region can become briefly active. This allows Type B regions to save more power during common battery life scenarios.



Faster Gate Exit

AMD designed the Ryzen Mobile APU to deliver 47% to 87% faster gate exits over the previous generation.

Next Page > How Fast Are The Ryzen Mobile & Radeon Vega Graphics?



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

How Fast Is The Ryzen Mobile CPU?

AMD shared the following performance results of the Ryzen Mobile CPU.

In this comparison, the AMD Ryzen 7 2700U is 8% faster than the Intel Core i7-8550U, and 10% faster than the Core i7-7500U in the single-core test.

When all four cores were enabled, the Ryzen 7 2700U was 44% faster than the Intel Core i7-8550U, and 2.2X faster than the Core i7-7500U!

Here are some additional benchmark results of the new AMD Ryzen 7 2700U and Ryzen 5 2500U APUs against the Intel Core i7-8550U and the previous-generation AMD FX-9800P APU.



Desktop-Class Performance

With the greatly-increased performance of the new Ryzen 7 2700U APU, AMD points out that it is slightly (7%) faster than the Intel Core i5-7600K – a quad-core desktop processor with 6X higher TDP!

[adrotate group=”1″]



How Fast Is Radeon Vega Graphics?

With just ten or eight Compute Units, the Radeon Vega GPU embedded into the Ryzen Mobile has nowhere near the performance of the Radeon RX Vega 64 or Vega 56 desktop graphics cards. However, they are still much faster than the mobile GPUs that both AMD and Intel have ever introduced in a mobile processor.

In the 3DMark Time Spy DirectX 12 test, the Ryzen 7 2700U with its 10 Compute Units was able to slightly beat the NVIDIA GeForce GTX 950M discrete graphics. That makes it about 2.5X faster than Intel HD Graphics.

What this means is the Radeon Vega Graphics in the AMD Ryzen 7 2700U is fast enough to deliver playable frame rates at 1080p resolution for most games.

Next Page > Battery Life, Thinner Profile, Performance Summary & Conclusion



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

Better Battery Life

As pointed out earlier, AMD claims that the Ryzen Mobile APUs will deliver 58% lower power consumption, compared to the 7th Generation AMD APUs. Their benchmark results show battery life improvements from 15% to 104%.



Thinner Profile

The AMD Ryzen Mobile is designed for ultra-thin notebooks. The AMD Ryzen Mobile APU itself will have a 24% thinner Max Z-Height. That may not mean a lot, but when it comes to mobile devices, every millimetre counts.



Performance Summary

Here is a spider chart that neatly summarises the performance advantage of the AMD Ryzen 7 2700U over the Intel Core i7-8550U.

[adrotate group=”1″]



Conclusion

There is no doubt that the AMD Ryzen Mobile APUs are AMD’s most advanced mobile processor. This isn’t hyperbole. It’s a fact that is backed by what we have seen with their Ryzen 7, Ryzen 5 and Ryzen 3 desktop processors, as well as their Radeon RX Vega desktop graphics cards.

Finally, after many years of producing mobile APUs with lacklustre performance and high power consumption, AMD may finally have a thoroughbred in the Ryzen Mobile. We can’t wait to see the ultra-thin notebooks that will use these new APUs!

Go Back To > First Page | Computer Hardware & Systems | Home



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

AMD Doubles Down On mGPU Frame Pacing

Adding to Radeon Software Crimson Edition’s enhancements for DirectX 9, DirectX 10, and DirectX 11, Radeon Software 16.9.1 enables multi-GPU frame pacing support to DirectX12 on all GCN-enabled GPUs and AMD A8 APUs or higher with GCN.

Frame pacing delivers consistency by increasing smoothness in gameplay. In multi-GPU (mGPU) configurations, GPUs render alternating frames and push each frame to your screen. Each render can be created at various speeds causing differences in frame time. With frame pacing enabled, frames are distributed evenly, i.e. with less variance between frames, creating liquid smooth gameplay. For more details, please watch the following video:



Radeon Tech Talk: DirectX 12 mGPU Frame Pacing

A number of games currently take advantage of frame pacing in DirectX 12. Total War – Warhammer, Rise of the Tomb Raider and the 3DMark Time Spy benchmark also show smoother run-throughs.

[adrotate banner=”5″]

Let’s look at the some real-life scenarios:



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!

The 7th Generation AMD PRO APUs Announced

Barcelonia, Spain, 3 October 2016 — Today at the Canalys Channels Forum, AMD announced the first PCs featuring 7th Generation AMD PRO APUs (formerly codenamed “Bristol Ridge PRO”). Built for business, AMD PRO APUs deliver increased computing and graphics performance, improved energy efficiency, while providing a secure and stable platform to protect customers’ IT investments.

“In the past two years we made incredible progress in the commercial client segment. Since its inception in mid-2014, AMD PRO processor unit shipments increased more than 45 percent, enabling businesses all over the world to simplify IT with secure, high performance, reliable solutions” said Jim Anderson, senior vice president and general manager, Computing and Graphics Business, AMD. “We are thrilled to have PC market leaders like HP and Lenovo expanding their use of AMD technology in their business client portfolios.”

“We’re delighted to offer 7th generation AMD PRO processors in our new HP EliteDesk 705 G3 desktop series,” said Guayente Sanmartin, Vice President of Product Management, Commercial Desktops, HP Inc. “We are delivering more performance, security and flexibility to give our enterprise customers peace of mind that allows them to focus on their business, not on IT complexity.”

New systems from HP and Lenovo combine commercial-grade quality, performance, and stability, with exceptional video and audio capabilities enabling businesses to achieve more across key areas including productivity, manageability, and collaboration. In addition, Microsoft Windows 10 Pro features including Device Guard, Windows Hello, Biometric Security and BitLocker Encryption are fully supported, out of the box.



7th Generation AMD PRO Processors

7th Generation AMD PRO processors tackle business needs in three key areas:

  • Help ensure sensitive data and trusted applications remain secure with the dedicated and integrated AMD Secure Processor technology; a system-wide secure environment that offloads and isolates security functions, providing an independent hardware-based root of trust for secure boot, content protection, application security, and fTPM 2.0 (firmware trusted platform module).
  • To meet users’ growing compute and graphic demands, new AMD PRO desktop processors provide up to 14% more compute and 22% more graphic performance while being up to 32% more energy efficient than 6th generation AMD PRO processors.
  • Open standards and CPU-agnostic DASH manageability allows IT departments to easily integrate and manage systems. The new AMD AM4 desktop infrastructure provides a stable and upgradable platform for the future.



AMD 7th Generation Systems

[adrotate group=”2″]

The HP EliteDesk 705 G3 Series desktops, available in microtower, small-form factor (SFF), or mini-form factor, deliver impressive value with uncompromising performance, security, and manageability for an enterprise-class experience.

The EliteDesk desktop PCs are more secure with HP Sure Start with Protection of BIOS Configuration and Policy. This helps to protect your PC and ensure uninterrupted productivity by automatically detecting and recovering from BIOS corruption or attacks. The desktops also include TPM 2.0 to secure data and HP’s full portfolio of physical-security accessories for a robust, three-layer security solution.

7th generation AMD PRO processors aim to deliver the best performance, reliability, and opportunity to handle critical workloads with planned availability in additional new PCs in the near future.

Go Back To > Enterprise | Home



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!

AMD Radeon RX 480 CrossFire Performance Comparison

You have seen our Radeon RX 480 review, so today, we are going to take a look at its CrossFire performance. For the uninitiated, that’s two Radeon RX 480 graphics cards running together.

You may recall that when Chief Architect of the Radeon Technologies Group, Raja Koduri, first revealed the Radeon RX 480, he made a startling claim that two Radeon RX 480 cards only utilized 51% of their processing capabilities to beat the GeForce GTX 1080 graphics card.

That was later clarified by Robert Hallock as a CPU-limited result. He also revealed that two Radeon RX 480 cards will deliver 83% better performance than a single Radeon RX 480 card.

Today, we are going to check out those claims in a variety of benchmarks and games. Let’s get down to it!



The Graphics Cards

Specifications Radeon R9 380 Radeon RX 480 GeForce GTX 1060 GeForce GTX 980 Ti GeForce GTX 1070 Radeon RX 480 CrossFire
Textures Per Clock 112 144 80 176 120 288
Pixels Per Clock 32 32 48 96 64 64
Clock Speed 970 MHz 1120 – 1266 MHz 1506 – 1708 MHz 1000 – 1075 MHz 1506 – 1683 MHz 1120 – 1266 MHz
Texture Fill Rate 108.6 GT/s 161.3 – 182.3 GT/s 120.5 – 136.6 GT/s 176.0 – 189.2 GT/s 180.7 – 202.0 GT/s 322.6 – 364.6 GT/s
Pixel Fill Rate 31.0 GP/s 35.8 – 40.5 GP/s 72.3 – 82.0 GP/s 96.0 – 104.5 GP/s 96.4 – 107.7 GP/s 71.7 – 81.0 GP/s
Graphics Memory 4 GB GDDR5 8 GB GDDR5 6 GB GDDR5 6 GB GDDR5 8 GB GDDR5 16 GB GDDR5

(8 GB effective)

Memory Bus Width 256-bits 256-bits 192-bits 384-bits 256-bits 256-bits x 2
Memory Speed 1425 MHz 1750 MHz 2000 MHz 1752.5 MHz 2000 MHz 1750 MHz
Memory Bandwidth 182.4 GB/s 224.0 GB/s 192.0 GB/s 336.5 GB/s 256.0 GB/s 448.0 GB/s
TDP 190 W 150 W 120 W 250 W 150 W 300 W
[adrotate banner=”5″]



Benchmarking Notes

Our graphics benchmarking test bed has the following specifications :

Operating SystemMicrosoft Windows 10 64-bit

ProcessorIntel Core i7 6700K processor running at 4.0 GHz

MotherboardASRock Z170 Extreme4

Memory8 GB DDR4-2133 memory (dual-channel)

Storage240 GB HyperX Savage SSD

MonitorDell P2415Q Ultra HD Monitor

We used the GeForce driver version 372.54 for all three NVIDIA graphics cards used in our tests.

We used the Radeon Software 16.8.2 driver for the AMD graphics cards used in our tests. In addition, we enabled the Compatibility Mode for the Radeon RX 480 cards to ensure that they keep to their rated 150 W TDP.

Next Page > 3DMark DirectX 12 and DirectX 11 Benchmark Results



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!

3DMark DirectX 12 Benchmark (2560 x 1440)

3DMark Time Spy is a new DirectX 12 benchmark that was released just days ago, just in time for this review. It supports new API features like asynchronous compute, explicit multi-adapter, and multi-threading.

In this DirectX 12 benchmark, the Radeon RX 480 CrossFire was 93% faster than the single Radeon RX 480. Very impressive. This allows the Radeon RX 480 CrossFire to beat the GeForce GTX 1070 by 33%. This gives the Radeon RX 480 CrossFire a slight (5.7%) price-performance advantage over the GeForce GTX 1070, albeit at twice the power consumption.



3DMark (1920 x 1080)

For Direct 11 performance, we started testing the graphics cards using 3DMark at the most common gaming resolution – 1920 x 1080.

At this relatively CPU-limited test, the Radeon RX 480 CrossFire was 95% faster than the single Radeon RX 480. It was also 31%-35% faster than the GeForce GTX 1070, 79-86% faster than the GeForce GTX 1060.

Note that the Radeon RX 480 CrossFire ended up about 12% slower than both the GeForce GTX 1070 and the GeForce GTX 980 Ti in the Combined Test, probably because it was CPU-limited.

[adrotate banner=”5″]



3DMark (2560 x 1440)

Then we took 3DMark up a notch to the resolution of 2560 x 1440. Let’s take a look!

As the higher 1440p resolution, the Radeon RX 480 CrossFire was 96% faster than the single Radeon RX 480. However, its performance advantage over the GeForce GTX 1070 and GeForce GTX 1060 dropped to 27% and 74% respectively.

At this point, the Radeon RX 480 CrossFire loses its price-performance advantage over the GeForce GTX 1070. However, it still maintains a comfortable price-performance advantage over the GeForce GTX 1080.



3DMark (3840 x 2160)

This is a torture test, perfect for comparing the GeForce GTX 1070 and the Radeon RX 480 CrossFire.

At the 4K resolution, the Radeon RX 480 CrossFire was 23% faster than the GeForce GTX 1070, and 73% faster than the GeForce GTX 1060. If we had a GeForce GTX 1080, the Radeon RX 480 CrossFire would likely be slightly faster, with a significant price-performance advantage, albeit with significantly higher power consumption.

Next Page > Ashes of the Singularity, Total War: Warhammer Benchmark Results



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

Ashes of the Singularity FAILED!

We tested Ashes of the Singularity in the DirectX 12 mode, which not only supports the new Asynchronous Compute feature, but is necessary to support the CrossFire mode for the two Radeon RX 480 cards.

Unfortunately, Ashes of the Singularity kept crashing whenever multi-GPU mode was enabled. There was simply no way to get it to run reliably, even though we tried 3 different driver versions.

As our GeForce GTX 1070 review shows, we have no issues running it with single graphics cards from both AMD and NVIDIA. It only failed when multi-GPU support was enabled. We will update this section when we finally get CrossFire mode running on Ashes of the Singularity.



Warhammer (1920 x 1080)

This chart shows you the minimum and maximum frame rates, as well as the average frame rate, recorded by Total War : Warhammer‘s internal DirectX 12 benchmark.

Looks like CrossFire isn’t working in Total War : Warhammer. The Radeon RX 480 CrossFire was actually 6.5% slower than the single Radeon RX 480 graphics card. It was just slightly faster than the GeForce GTX 1060.



Warhammer (2560 x 1440)

This chart shows you the minimum and maximum frame rates, as well as the average frame rate, recorded by Total War : Warhammer‘s internal DirectX 12 benchmark.

At the higher 1440p resolution, the Radeon RX 480 CrossFire was 7.7% slower than the single Radeon RX 480 graphics card, and 3.7% slower than the GeForce GTX 1060.



Warhammer (3840 x 2160)

This chart shows you the minimum and maximum frame rates, as well as the average frame rate, recorded by Total War : Warhammer‘s internal DirectX 12 benchmark.

At the 4K resolution, the Radeon RX 480 CrossFire was 4.9% slower than the single Radeon RX 480 graphics card, and 6.9% slower than the GeForce GTX 1060. It would definitely be a good idea to disable CrossFire mode when you play Total War : Warhammer.

Next Page > The Witcher 3 and Fallout 4 Benchmark Results



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

The Witcher 3 (1920 x 1080)

This chart shows you the minimum and maximum frame rates, as well as the average frame rate, that FRAPS recorded in The Witcher 3.

The CrossFire mode worked in The Witcher 3 though. The Radeon RX 480 CrossFire achieved an average frame rate in excess of 100 fps. That makes its 59% faster than the single Radeon RX 480 graphics card, 49.6% faster than the GeForce GTX 1060, and 5% faster than the GeForce GTX 1070.



The Witcher 3 (2560 x 1440)

This chart shows you the minimum and maximum frame rates, as well as the average frame rate, that FRAPS recorded in The Witcher 3.

The Radeon RX 480 CrossFire maintained its performance lead at the 1440p resolution. It was 59% faster than the single Radeon RX 480 graphics card, 47.8% faster than the GeForce GTX 1060, and 5.6% faster than the GeForce GTX 1070.



The Witcher 3 (3840 x 2160)

This chart shows you the minimum and maximum frame rates, as well as the average frame rate, that FRAPS recorded in The Witcher 3.

The Radeon RX 480 CrossFire increased its performance lead at the 4K resolution. It was now 64.4% faster than the single Radeon RX 480 graphics card, 52.3% faster than the GeForce GTX 1060, and 8.9% faster than the GeForce GTX 1070.

[adrotate banner=”5″]



Fallout 4 (1920 x 1080)

This chart shows you the minimum and maximum frame rates, as well as the average frame rate, that FRAPS recorded in Fallout 4.

CrossFire did not work in Fallout 4, at least not in 1080p. The Radeon RX 480 CrossFire was actually 2.7% slower than the single Radeon RX 480 graphics card, and 16% slower than the GeForce GTX 1060.



Fallout 4 (2560 x 1440)

This chart shows you the minimum and maximum frame rates, as well as the average frame rate, that FRAPS recorded in Fallout 4.

At the higher 1440p resolution, the CrossFire mode finally kicked in. The Radeon RX 480 CrossFire actually became 24% faster than the single Radeon RX 480 graphics card, and 9.6% faster than the GeForce GTX 1060.



Fallout 4 (3840 x 2160)

This chart shows you the minimum and maximum frame rates, as well as the average frame rate, that FRAPS recorded in Fallout 4.

Amazingly, when we hit 4K, the CrossFire mode really showed its mettle. The Radeon RX 480 CrossFire was now 62% faster than the single Radeon RX 480 graphics card, and 43.2% faster than the GeForce GTX 1060.

The Radeon RX 480 CrossFire even edged out the GeForce GTX 1070, and beat the GeForce GTX 980 Ti by 8.7%.

Next Page > Radeon RX 480 CrossFire Performance Summary, Our Opinion



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

Performance Summary

Here is a summary of our benchmark results. We highlighted the benchmarks in which the CrossFire mode worked (in green), and when it didn’t work (in red).

Benchmarks Radeon R9 380 Radeon RX 480 GeForce GTX 1060 GeForce GTX 980 Ti GeForce GTX 1070 Radeon RX 480 CrossFire
Time Spy (1440p) Slower by 65.1% Slower by 48.2% Slower by 45.8% Slower by 36.5% Slower by 24.8% Baseline
Fire Strike (1080p) Slower by 64.0% Slower by 48.8% Slower by 45.2% Slower by 28.7% Slower by 25.1% Baseline
Fire Strike Extreme (1440p) Slower by 63.4% Slower by 49.0% Slower by 42.4% Slower by 25.1% Slower by 21.2% Baseline
Fire Strike Ultra (2160p) Slower by 61.2% Slower by 48.3% Slower by 42.1% Slower by 22.5% Slower by 18.8% Baseline
Ashes of the Singularity Failed
Total War: Warhammer (1080p) Slower by 26.1% Faster by 7.0% Slower by 0.5% Faster by 30.7% Faster by 36.1% Baseline
Total War: Warhammer (1440p) Slower by 26.4% Faster by 8.4% Faster by 3.9% Faster by 40.3% Faster by 43.8% Baseline
Total War: Warhammer (2160p) Slower by 29.4% Faster by 5.1% Faster by 7.5% Faster by 48.6% Faster by 51.0% Baseline
The Witcher 3 (1080p) Slower by 57.6% Slower by 37.2% Slower by 33.1% Slower by 8.0% Slower by 4.8% Baseline
The Witcher 3 (1440p) Slower by 57.0% Slower by 37.2% Slower by 33.1% Slower by 7.8% Slower by 5.3% Baseline
The Witcher 3 (2160p) Slower by 57.5% Slower by 39.2% Slower by 34.4% Slower by 10.2% Slower by 8.1% Baseline
Fallout 4 (1080p) Slower by 20.5% Faster by 2.8% Faster by 19.1% Faster by 27.8% Faster by 29.6% Baseline
Fallout 4 (1440p) Slower by 41.7% Slower by 19.6% Slower by 8.7% Faster by 16.7% Faster by 22.6% Baseline
Fallout 4 (2160p) Slower by 54.3% Slower by 38.1% Slower by 30.2% Slower by 8.0% Slower by 1.1% Baseline



Our Opinion

The Radeon RX 480 CrossFire showed great promise in the 3DMark benchmarks. It was able to deliver 93% to 96% better performance than a single Radeon RX 480 graphics card.

The actual boost in frame rate was smaller, of course, due to CPU limits. But it proved to be faster than the GeForce GTX 1070 by 15% to 18% in DirectX 11, and 26% in DirectX 12. Very impressive.

Unfortunately, we do not have an NVIDIA GeForce GTX 1080 in our benchmark suite, but we know that it is roughly 20%-25% faster than the GeForce GTX 1070. So we can guesstimate that the Radeon RX 480 CrossFire will be slightly faster than the GeForce GTX 1080 in DirectX 12, and slightly slower in DirectX 11.

[adrotate banner=”4″]

From a price-performance perspective, the Radeon RX 480 CrossFire ties with the GeForce GTX 1070, if we only take into account the 3DMark results. It loses out to the GeForce GTX 1070 when it comes to actual games, particularly in games that don’t work well or at all with CrossFire.

As you can tell from the table above, the reliability of the CrossFire mode is still quite iffy. That is really too bad, because the 3DMark results show that the Radeon RX 480 CrossFire has great potential, particularly in DirectX 12.

If AMD can get the CrossFire mode to work in all games, the Radeon RX 480 CrossFire is a great alternative to the GeForce GTX 1080. It offers equivalent performance at a 20% discount (US$478 vs. US$599), albeit with much higher power consumption (300W vs. 180W).



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

The 7th Generation AMD A-Series Desktop APUs Revealed

Today, AMD officially revealed the first 7th Generation AMD A-Series desktop APUs running on the new Socket AM4. Previously codenamed Bristol Ridge, the new 7th Generation AMD A-Series desktop APUs will start shipping soon in HP and Lenovo devices.

Be sure to check out our companion articleThe New AMD Socket AM4 Chipsets Revealed.



The 7th Gen AMD A-Series Desktop APU Revealed

With up to four “Excavator” cores, the 7th Generation AMD A-Series desktop APUs consist of 65-watt and 35-watt versions, with greatly improved graphics capabilities and power efficiency. Check out this presentation by Peter Amos, APU Product Marketing Manager, AMD Client Business Unit, AMD. You may recall his earlier presentation here.



The First 7th Generation AMD A-Series Desktop APUs

Here is the first slew of 7th Generation AMD A-Series desktop APUs released by AMD :

APU Models Cores Base Frequency Max Frequency Processor Graphics Graphics CUs Graphics Frequency
AMD A12-9800 4 3.8 GHz 4.2 GHz Radeon R7 8 CUs 1108 MHz
AMD A12-9800E 4 3.1 GHz 3.8 GHz Radeon R7 8 CUs 900 MHz
AMD A10-9700 4 3.5 GHz 3.8 GHz Radeon R7 6 CUs 1029 MHz
AMD A10-9700E 4 3.0 GHz 3.5 GHz Radeon R7 6 CUs 847 MHz
AMD A8-9600 4 3.1 GHz 3.4 GHz Radeon R7 6 CUs 900 MHz
AMD Athlon X4 950 4 3.5 GHz 3.7 GHz None
AMD A6-9500 2 3.5 GHz 3.8 GHz Radeon R5 6 CUs 1029 MHz
AMD A6-9500E 2 3.0 GHz 3.4 GHz Radeon R5 4 CUs 800 MHz
[adrotate banner=”5″]



The 7th Generation AMD A-Series Desktop APU Slides

For those who prefer to go through the presentation slides in detail, here they are for your perusal :

Be sure to check out our companion article – The New AMD Socket AM4 Chipsets Revealed.



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!

AMD Zen Sneak Peek @ Hot Chips 2016

If you recall, AMD publicly revealed the first processor to use the AMD Zen microarchitecture on the second day of Computex 2016. Codenamed “Summit Ridge“, the desktop processor will come with eight AMD Zen processor cores that are capable of processing sixteen threads simultaneously.



AMD Zen Sneak Peek

AMD today gave us a sneak peek of the AMD Zen processor architecture. AMD Senior Fellow and Design Engineer, Michael Clark, gave a 26-minute long technical briefing on the AMD Zen architecture at the Hot Chips Symposium in Cupertino, California. Here are the key takeaway points :

[adrotate banner=”4″]
  • Zen delivers 40% more instructions per clock than the current Excavator core.
  • Zen is highly scalable and will be used in every future AMD mobile, desktop or server processor.
  • Zen has a better core engine that handles two threads per core, and boasts a large Op Cache, wide micro-op dispatch, as well as larger instruction schedulers, Retire Queue, Load Queue and Store Queue.
  • Zen has a better cache system too, with almost double the L1 and L2 bandwidth, and 5X better L3 bandwidth.
  • Zen is the first AMD microarchitecture to emphasise low power design, using aggressive clock gating with multi-level regions, as well as other microarchitecture tricks to greatly reduce power consumption.



AMD Zen Technical Briefing @ Hot Chips 2016

We prepared a video presentation of Clark’s technical briefing at Hot Chips 2016 for your enjoyment. Check it out!

[adrotate banner=”5″]



AMD Zen Sneak Peek Slides : Performance

For those who prefer to go through the slides, here they are for your perusal :

Next Page > In-Depth Design, New Instructions, Summary



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!

AMD Zen Design In-Depth

[adrotate banner=”5″]



AMD Zen Sneak Peek : New Instructions



AMD Zen Sneak Peek : Summary



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!

AMD Polaris GPU & 7th Generation APU Tech Briefings

AMD officially revealed the AMD Polaris GPUs and the 7th Generation AMD APUs at Computex 2016. The first graphics card based on the AMD Polaris architecture was the AMD Radeon RX 480, and that was officially launched on June 29th.

As part of their aggressive push to promote both the Radeon RX 480, and 7th Generation AMD APUs; David Nalasco and Peter Amos flew all the way from AMD Markham in Canada to give a thorough tech briefing on the new AMD technologies in those products.

BONUS : We stumbled upon the first Radeon RX 460 seen in action. Check it out here!



AMD Polaris Launch

Ryan Sim, Channel Sales Director of AMD ASEAN & India, started the event with a short welcome speech. He pointed out how the new AMD Radeon RX 480 offers unrivalled power efficiency, and brings virtual reality to the mainstream with a shockingly affordable price.

Then AMD officially launched the AMD Radeon RX 480 here in Malaysia, with this launch gambit. Check it out!

[adrotate banner=”5″]



AMD Polaris GPU Tech Briefing

In this video, David Nalasco, Senior Technology Manager for Graphics in the Radeon Technology Group, gives a thorough tech briefing on the new AMD Polaris architecture, and the first three graphics cards based on the Polaris 10 and Polaris 11 GPUs.



AMD 7th Generation APU Tech Briefing

Then Peter Amos, APU Product Marketing Manager, AMD Client Business Unit, gave a tech briefing on the new 7th Generation AMD APUs, as well as upcoming desktop processors based on the new AMD Zen architecture. Check it out!

[adrotate banner=”5″]



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!

7th Generation AMD A-Series APUs Revealed

On the second day of Computex 2016, AMD unveiled the 7th Generation AMD A-Series APUs at the Westin Taipei. Shipping in volume to OEM customers, the new 7th Generation AMD A-Series APUs feature up to 4 mobile-optimised “Excavator” x86 CPU cores, with built-in Radeon graphics cores.

The 7th Generation AMD A-Series is divided into two families, codenamed “Bristol Ridge” and “Stoney Ridge“. The “Bristol Ridge” family consists of 35- and 15-watt versions of AMD FX, A12, and A10 processors, while “Stoney Ridge” family will power the 15-watt A9, A6 and E2 processors.



7th Generation AMD A-Series APUs Revealed

We were present at the Westin Taipei, when Jim Anderson, Senior Vice President and General Manager, Computing and Graphics Business Group, AMD unveiled the 7th Generation AMD A-Series APUs. Check it out!

Here is a summary of the key points from the presentation :
  • The 7th Generation AMD FX processor will deliver up to 53% better graphics performance, and up to 51% better compute performance, than the Intel Core i7 processor.
  • “Stoney Ridge” APUs will deliver up to 50% better CPU core performance over the previous-generation “Carrizo” APUs.
  • The new AMD A9-9410 APU will deliver up to 27% better graphics performance than the Intel Pentium 4405U, and rival the Intel Core i3-6100U in both graphics and compute performance.
  • DDR4 memory support and Adaptive Voltage and Frequency Scaling (AVFS) technology in the new APUs give them 25% better performance per watt.

These new APUs will use the new AMD AM4 socket that is also used by the upcoming AMD “Summit Ridge” desktop processor based on their new “Zen” microarchitecture.

[adrotate banner=”5″]



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!

AMD Technologies Revealed at Computex 2016

On the second day of Computex 2016, AMD held a press conference at the Westin Taipei. In that hour-long press conference, they announced multiple updates on their latest and upcoming processor and graphics technologies. The key AMD technologies revealed at the press conference include :



AMD Polaris Architecture

The unveiling of the upcoming AMD Polaris architecture-based Radeon RX series of graphics cards. The AMD Radeon RX Series will be headlined by the AMD Radeon RX 480, providing great 3D and VR performance at just US$199. The AMD Radeon RX 480 will be formally launched on June 29, 2016



7th Generation AMD A-Series Mobile APUs

The launch of the new 7th Generation AMD A-Series mobile APUs (Accelerated Processing Units). They will deliver significant double-digit improvements in gaming, video rendering and file compression performance, over the previous 6th Generation AMD A-Series mobile APUs.



Future AMD “Summit Ridge” Desktop Processor

The first public revelation of the upcoming AMD “Summit Ridge” desktop processor. Based on AMD’s next-generation x86 “Zen” processor core, the AMD “Summit Ridge” desktop processor will have eight cores that are capable of simultaneously handling sixteen threads.



The AMD Technologies Update Press Conference

Here is the full hour-long AMD press conference at the Westin Taipei during Computex 2016. The speakers include :

  • Dr. Lisa Su, President and Chief Executive Officer, AMD
  • Raja Koduri, Senior Vice President and Chief Architect, Radeon Technologies Group
  • Jim Anderson, Senior Vice President and General Manager, Computing and Graphics Business Group, AMD
  • Matt Perry, Partner Group Program Manager, Microsoft
  • Josephine Tan, Vice President, Consumer Product Management (Notebook and Premium), HP
  • Ray Wah, Vice President, Consumer Product Group, Dell

“We entered 2016 with a great product lineup and growing momentum for AMD’s technologies,” said AMD President and CEO Dr. Lisa Su. “Today’s launch of our 7th Generation A-Series mobile APUs, to be followed closely by new Radeon RX Series GPUs and then our next-generation ‘Summit Ridge’ desktop processor powered by our ‘Zen’ core represent key proof points of our strategy to firmly re-establish AMD as a high-performance design leader.” [adrotate banner=”5″]



Support Tech ARP!

If you like our work, you can help support our work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!

HP ProBook 645 & 655 To Feature AMD PRO A-Series CPU

February 11, 2016 AMD (NASDAQ: AMD) today announced increasing momentum for the 6th Generation AMD PRO A-Series mobile processors, based on the introduction of two new HP (NYSE: HPQ) notebook design wins, new large-scale enterprise deployments, and the expansion of HP adoption of AMD FreeSync technology in its notebooks and displays.

The 6th Generation AMD PRO A-Series processors, which efficiently integrate extensive AMD CPU, graphics, security, and video processing IP into a single SoC design, will now power two new HP 600 series ProBooks.

The HP ProBook 645 14-inch and HP ProBook 655 15.6-inch notebooks allow businesses to equip their workforces with widely configurable and extremely cost-effective HP notebook PCs, enabling executive-class collaboration and professional-grade capabilities. Containing AMD PRO A-Series processors with brilliant AMD Radeon graphics, Windows 10, robust DDR3 memory, and professional-grade peripheral devices, these HP ProBooks create a top-of-the-line user experience.



6th Generation AMD A-Series processors powering the workplace

[adrotate banner=”4″]Market momentum for joint AMD and HP solutions is seen in the continued adoption of HP laptops powered by AMD processors by companies around the world. For example, ISS, a global facilities services provider with 511,000 employees in 77 countries, recently equipped employees with HP EliteBooks powered by AMD PRO A-Series processors in an effort to standardize global operations, increase sustainability and innovate business-efficient office environments.

Brink’s, a global leader in security-related services with customers in more than 100 countries, wanted an IT solution that offered outstanding stability and mobility, and found it in the HP EliteBook 700 series, also powered by AMD. Stability is critical to supporting Brink’s all-day, every-day workforce with mobile-ready features, and industry leading manageability that drives nonstop productivity. The innovative AMD PRO A-Series processor architecture offers all-day battery life[i], power and efficiency optimized for employees all around the world.



AMD FreeSync adoption

Additionally, HP plans to enable AMD FreeSync technology support for its consumer-focused HP Envy 15z laptops powered by 6th Generation AMD A-Series processors. AMD FreeSync technology resolves the communication issues between processor and monitor to eliminate stutter and tearing, providing a smoother image[ii]. HP anticipates having AMD FreeSync-enabled HP Envy 15z laptops available in the first half of 2016, and plans to enable AMD FreeSync support across its entire consumer laptop line-up powered by 6th Generation AMD A-Series processors in the second half of the year.

Personal and commercial HP notebooks powered by 6th Generation AMD A-Series processors are available now through major retailers.

[i] AMD defines All-Day Battery Life as 8+ hours of continuous use when measured with the Windows Idle test.

[ii] FreeSync is an AMD technology designed to eliminate stuttering and/or tearing in games and videos by locking a display’s refresh rate to the framerate of the graphics card. Monitor, AMD Radeon Graphics and/or AMD A-Series APU compliant with DisplayPort Adaptive-Sync required. AMD Catalyst 15.2 Beta (or newer) required. Adaptive refresh rates vary by display; check with your monitor manufacturer for specific capabilities.



Support Tech ARP!

If you like our work, you can help support out work by visiting our sponsors, participating in the Tech ARP Forums, or even donating to our fund. Any help you can render is greatly appreciated!

AMD A10-7860K, A6-7470K & Athlon X4 845 APUs Launched

February 2, 2016 – AMD officially launched three new desktop processors – the AMD A10-7860K, the AMD A6-7470K and the AMD Athlon X4 845. Let’s take a look!



AMD A10-7860K “Godavari” Desktop Processor

Based on the Godavari core, the new AMD A10-7860K offers only a slight performance boost over the Kaveri-based A10-7850K. However, the improvements in fabrication technology and binning process allowed for a more efficient processor. This dropped the A10-7860K’s TDP to just 65 W. Compare that to the A10-7850K which has a 95 W TDP.

The A10-7860K slides in between the two existing Kaveri-based A10-7870K and A8-7670K processors. AMD will also introduce a faster A10-7890K later in Q1, 2016.

Even though the A10-7860K has a TDP of 65 W, AMD will continue to include a 95 W cooler with it. It does not, however come with the new AMD Wraith cooler. It will feature the new and improved AMD 95 W quiet cooler instead.



Two New Kaveri Processors Join The Team

AMD also announced two new Kaveri-based processors – the AMD A6-7470K and the AMD Athlon X4 845. The A6-7470K is a dual-core APU with a quad-core GPU and 1 MB of L2 cache. The Athlon X4 845, on the other hand, has four cores but lacks graphics capability.

The A6-7470K will come with a standard 65 W cooler, while the Athlon X4 845 comes with the new and improved AMD 95 W quiet cooler.



Support Tech ARP!

If you like our work, you can help support out work by visiting our sponsors, participate in the Tech ARP Forums, or even donate to our fund. Any help you can render is greatly appreciated!
